1 |
58B-50-00760
|
HOUSING |
1 |
|
|
|
|
2 |
WA3925
|
DECAL, HYDRAIR II |
2 |
|
|
|
|
3 |
09659-A0881
|
PLATE, SAFETY |
4 |
|
|
|
|
4 |
58B-93-00650
|
DECAL, SHOP MANUAL |
4 |
|
|
|
|
5 |
58B-50-00710
|
RETAINER, UPPER BEARING |
1 |
|
|
|
|
6 |
WA0363
|
FLAT WASHER, HARDENED - 7/8" |
60 |
|
|
|
|
7 |
VN9105
|
CAPSCREW - 7/8" - 9NC X 3" |
36 |
|
|
|
|
8 |
58B-60-01240
|
BEARING, UPPER |
1 |
|
|
|
|
9 |
58B-50-00920
|
LOCKPIN (1) |
1 |
|
|
|
|
10 |
58B-50-00040
|
NUT, WHEEL |
1 |
|
|
|
|
11 |
58B-50-00890
|
STOP, PISTON |
1 |
|
|
|
|
12 |
SC3100
|
KEY, SQUARE |
1 |
|
|
|
|
13 |
58B-50-40380
|
O-RING (1) |
4 |
|
|
|
|
14 |
58B-50-40390
|
RING, BACKUP (1) |
4 |
|
|
|
|
15 |
58B-50-00790
|
CAP, SUSPENSION |
1 |
|
|
|
|
16 |
TY8879
|
PLUG, VENT (1) |
1 |
|
|
|
|
17 |
VD5076
|
GASKET, FLAT (1)/(2) |
1 |
|
|
|
|
18 |
PB2194
|
CHARGING VALVE ASSEMBLY (1)/(2) |
1 |
|
|
|
|
19 |
|
(NOT USED IN THIS APPLICATION) |
-1 |
|
|
|
|
20 |
C1602
|
CAPSCREW - 3/8" - 16NC X 1" |
2 |
|
|
|
|
21 |
DF3042
|
FLAT WASHER - 3/8" |
2 |
|
|
|
|
22 |
TZ8637
|
PLUG, SENSOR |
1 |
|
|
|
|
23 |
58B-60-01230
|
BEARING, LOWER |
1 |
|
|
|
|
24 |
58B-50-50000
|
RETAINER, LOWER BEARING |
1 |
|
|
|
|
25 |
58B-60-01220
|
SEAL, BUFFER (1) |
1 |
|
|
|
|
26 |
58B-50-00180
|
SEAL, WIPER (1) |
1 |
|
|
|
|
27 |
VN9161
|
CAPSCREW - 7/8" - 9NC X 4" |
24 |
|
|
|
|
28 |
VN2710
|
CAPSCREW - 1" - 8NC X 5 1/2" |
28 |
|
|
|
|
29 |
WA0364
|
FLAT WASHER, HARDENED - 1" |
28 |
|
|
|
|
30 |
58B-50-40370
|
SEAL, MAIN (1) |
1 |
|
|
|
|
31 |
58B-50-00800
|
PISTON ASSEMBLY |
1 |
|
|
|
|
32 |
H2981
|
BALL, STEEL (1) |
4 |
|
|
|
|
33 |
58B-50-00170
|
PLATE, WIPER RETAINER |
4 |
|
|
|
|
34 |
WA0443
|
O-RING (1) |
1 |
|
|
|
|
35 |
WA1443
|
RING, BACKUP (1) |
1 |
|
|
|
|
36 |
EM3159
|
PLUG, PISTON |
1 |
|
|
|
|
37 |
EM1585
|
RING, RETAINER |
3 |
|
|
|
|
38 |
EM1600
|
PLATE, RETAINER |
1 |
|
|
|
|
39 |
VM0314
|
PLUG (1) |
1 |
|
|
|
|
40 |
WA0360
|
FLAT WASHER, HARDENED - 1/2" |
1 |
|
|
|
|
41 |
VN9032
|
CAPSCREW - 1/2" - 13NC X 1" |
1 |
|
|
|
|
42 |
58F-50-00370
|
PLUG |
1 |
|
|
|
|
NS|43 |
|
NOTE: NS = NOT SHOWN |
-1 |
|
|
|
|
NS|44 |
AK4063
|
SUSPENSION OIL MIXTURE - 5 GAL |
-1 |
|
|
|
|
NS|45 |
AK4064
|
SUSPENSION OIL MIXTURE - 55 GAL |
-1 |
|
|
|
|
NS|46 |
58B-FS-AK020
|
NOTE: (1) INCLUDED IN 58B-FS-AK020 SEAL KIT. |
-1 |
|
|
|
|
NS|47 |
RK1887
|
(2) INCLUDED IN RK1887 CHARGING VALVE KIT. |
-1 |
|
|
|
|
NS|48 |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
