AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-06-00606	HARNESS, WIRING - CAB DIAGNOSTIC	1
?	WB1302	CLAMP, CUSHIONED - 5/16"	3
?	58E-06-80050	CABLE, CAT5E	1
?	58E-06-80040	CABLE, CAT5E	1
?	58E-06-00612	HARNESS, WIRING - CAB DASH	1
?	58E-06-00623	HARNESS, WIRING - CAB OVERHEAD	1
?	MM0177	NUT - M8 X 1.25	11
?	MM0460	FLAT WASHER - M8	11
?	WB3096	CLAMP, CUSHIONED - 1 1/4"	2
?	PC0618	PLUG, TERMINATING	1
?	PC0616	RECEPTACLE, TEE	5
?	XB6447	PLUG, 3-POSITION	4
?	WB1303	CLAMP, CUSHIONED - 3/4"	3
?	MM0019	CAPSCREW - M6 X 1.00 X 16	1
?	MM0469	LOCKWASHER - M6	1
?	EJ6371	CONNECTOR, CN2B	1
?	PC1701	FITTING, BULKHEAD COAX	2
?	WB3094	CLAMP, CUSHIONED - 1 3/4"	5
?	VN0137	CLAMP, CUSHIONED - 7/16"	3
?	08193-21012	CLIP	1
?	08193-20012	CLIP	2
?	VC7674	CLAMP - 2 7/16"	2
?	58E-54-19920	CONDUIT	1
?	58E-54-50300	MAT, RUBBER	1
?	58E-06-09220	CABLE, CAT5E	1
?	58E-06-00593	HARNESS, WIRING - CAB/DRIVE SIGNAL	1
?	WB3093	CLAMP, CUSHIONED - 1"	2
?	MM0605	CAPSCREW - M10 X 1.50 X 25	2
?	01643-31032	WASHER - M10	2
?	TD2186	GROMMET, RUBBER	2
?	08193-31012	CLIP	2
?	426-06-11570	BRACKET	1
?	MM0603	CAPSCREW - M10 X 1.50 X 16 (ZINC)	1
?	MM0461	FLAT WASHER - M10	1
?	WB1301	CLAMP, CUSHIONED - 1/4"	1
?	WB4010	NAME PLATE - CAN RPC	1
?	WB4009	NAME PLATE - CAN J1939	1
?	58E-06-40520	NAME PLATE - CAN	1
?	MM0205	LOCKWASHER - M4	2
?	MM0344	MACHINE SCREW - M4 X 0.7 X 20	2
?	MM0378	LOCKWASHER, EXTERNAL TOOTH - M4	2
?	MM0372	NUT - M4 X 0.7	2
?	MM0331	MACHINE SCREW - M3 X 0.5 X 20	4
?	MM0376	LOCKWASHER, EXTERNAL TOOTH - M3	4
?	MM0370	NUT - M3 X 0.5	4

Komatsu AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA parts catalog PDF

INTERNAL CAB WIRING 1/2 (47473) in AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA. Diagram image and parts list.
