AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-61-50030	BRAKE VALVE SUB-ASSEMBLY	1
?	BF2584	CAPSCREW	3
?	BF2588	NUT	2
?	BF2582	FOOT PAD, RUBBER	1
?	BF2587	PEDAL ACTUATOR	1
?	BF2585	NUT	1
?	XA3393	PIN, PEDAL	1
?	BF1858	BEARING, FLANGED NYLON	6
?	VE8835	RING, RETAINING	2
?	XA3392	PEDAL ASSEMBLY	1
?	XA3394	PEDAL ACTUATOR, ELECTRONIC	1
?		STOP, BOTTOM PIVOT (1)	1
?	VE8538	NUT	1
?	BF1854	BOLT	1
?		STOP, TOP PIVOT (1)	1
?	BF1857	SHIM	-1
?		SPRING, INNER (1)	1
?		SPRING, OUTER (1)	1
?	XA3389	PIN, ACTUATOR	1
?	XA3395	RING, RETAINING	2
?	MM0460	FLAT WASHER - M8	2
?	MM0594	CAPSCREW - M8 X 1.25 X 25	2
?	58F-00-00260	NOTE: (1) INCLUDED IN 58F-00-00260 SPRING & STOP KIT.	-1

Komatsu AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA parts catalog PDF

RETARD/BRAKE VALVE ASSEMBLY 58F-61-00001 (69381) in AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA. Diagram image and parts list.
