AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EK5654	TUBE, BENT - LH OUTER FRONT	1
?	VW7882	HOSE	1
?	WB1177	CLAMP, T-BOLT	16
?	EJ9919	BRACKET, MOUNTING	1
?	MM0462	FLAT WASHER - M12	2
?	MM0616	CAPSCREW - M12 X 1.75 X 20	2
?	WB1179	CLAMP, T-BOLT	4
?	EK5666	TUBE, BENT - LH MIDDLE FRONT	1
?	PB1597	ELBOW, RUBBER	1
?	EK5657	TUBE, BENT - LH INNER FRONT	1
?	TX6040	ELBOW, RUBBER - 45 DEG	1
?	TB1018	RAIN GUARD, SIDE	2
?	TB1017	RAIN GUARD	1
?	TR2961	CAPSCREW - 5/8" - 11NC X 1"	8
?	VC1390	LOCKWASHER - 5/8"	8
?	TR9082	FLAT WASHER - 5/8"	8
?	TB1019	RAIN GUARD, SIDE	2
?	TB1406	RAIN GUARD, FRONT	1
?	58B-02-00970	AIR CLEANER ASSEMBLY, SINGLE (SEE FIG 43407)	1	43407
?	EJ0609	SHEET	1
?	58F-02-00160	AIR CLEANER ASSEMBLY, DUAL (SEE FIG 68056)	1	68056
?	EH9685	TUBE, MIDDLE REAR - LH	1
?	58B-54-05110	TUBE, OUTER REAR - LH	1
?	XB9559	TUBE, LH INNER REAR	1
?	PC1115	HOSE, DOUBLE HUMP	3
?	EG8033	CLAMP, DOUBLE	2
?	TR4434	CAPSCREW - 3/8" - 16NC X 2"	3
?	HE5611	LOCKNUT - 3/8" - 16NC	3
?	WA4726	FLAT WASHER, HARDENED - 3/8"	3
?	WB1169	CLAMP, T-BOLT	9
?	EH9965	HOSE, TURBO CONNECTION	3
?	WB1178	CLAMP, T-BOLT	4

Komatsu AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA parts catalog PDF

AIR CLEANER PIPING - LEFT (61489) in AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA. Diagram image and parts list.
