AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	58B-50-00400	REAR SUSPENSION W/ BEARINGS	1
?	58B-50-00410	REAR SUSPENSION ASSEMBLY (1) (SEE FIG 47570)	1	47570
?	58B-50-00590	BEARING, SPHERICAL (2)	2
?	58B-50-00080	RING, RETAINING (2)	4
?	58B-50-00550	SPACER (2)	4
?	58B-50-00540	SLEEVE, PIN	2
?	58B-50-00560	PIN, BEARING (2)	2
?	58B-50-00600	SHOULDER BOLT - 5/8" - 11NC X 9.09" (FRAME END)	1
?	58B-50-00610	SHOULDER BOLT - 5/8" - 11NC X 8.27" (AXLE END)	1
?	WA0361	FLAT WASHER, HARDENED - 5/8"	2
?	VN9952	LOCKNUT - 5/8" - 11NC (2)	2
?	58B-80-00360	MUD FLAP (2)	1
?	58B-80-00340	BAR, FLAT	1
?	MM0597	CAPSCREW - M8 X 1.25 X 40	5
?	MM0470	LOCKWASHER - M8	5
?	MM0712	FLAT WASHER, HARDENED - M8	5
?		NOTE: NS = NOT SHOWN	-1
?	WA3925	DECAL, HYDRAIR II	1
?		NOTE: (1) NOT SERVICED SEPARATELY. ORDER 58B-50-00400.	-1
?	58B-MP-AK140	(2) INCLUDED IN 58B-MP-AK140 REAR SUSPENSION PIN KIT.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1

Komatsu AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA parts catalog PDF

REAR SUSPENSION INSTALLATION (60941) in AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA. Diagram image and parts list.
