AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	VE4064	SEAL, DUST (1)	1
?	VE3080	HOUSING/SPOOL/SLEEVE	1
?	VE3081	BALL	1
?	VE3082	BUSHING, THREADED	1
?	BF3031	O-RING (1)	1
?	VE3083	BEARING ASSEMBLY	1
?	VE3084	RING	1
?	VE3085	CROSS PIN	1
?	BF3032	SPRING SET (QTY. 6)	1
?	BF1287	SHAFT, CARDAN	1
?	VE4069	O-RING (1)	1
?	BF3033	PLATE, INTERMEDIATE	1
?	VE4071	O-RING (1)	3
?	BF3034	PLATE, DISTRIBUTOR	1
?	BF3035	GEAR WHEEL SET	1
?	VE3091	COVER, END	1
?	VE4072	WASHER (1)	7
?	BF3036	CAPSCREW W/ PIN (SPECIAL)	1
?	BF3037	CAPSCREW	6
?		NAME PLATE (2)	1
?		DRIVE SCREW (2)	1
?		NOTE: NS = NOT SHOWN	-1
?	BF3031	O-RING	1
?	BF3038	NOTE: (1) INCLUDED IN BF3038 SEAL KIT.	-1
?		(2) NOT SERVICED SEPARATELY.	-1

Komatsu AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA parts catalog PDF

STEERING CONTROL UNIT PB9881 (60104) in AFE73-T 980E-4 S/N A40160 - A40162 BUENAVISTA. Diagram image and parts list.
