Diagram image 1 of 3

PC3000-6E S/N 06361

? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6E S/N 06361

? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6E S/N 06361

? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	798 884 73	Lube pump assy.	1
?	790 935 73	Cylinder assy. with control block	1
?		Cylinder	1
?		Lock washer	4
?		Suction tube assy. + Scraper ring	1
?	790 658 73	Cover	-2
?		Lock washer	4
?		Tapping screw	4
?	769 000 73	Flow control valve	1
?	769 001 73	Pressure reducing valve	1
?		Scraper ring	1
?	769 002 73	Bolt	1
?	769 003 73	Adapter	1
?	769 004 73	Piston rod	1
?	769 005 73	Bushing	1
?		O-ring	1
?		V-seal	1
?		Supporting disc	1
?		Circlip	1
?	769 006 73	Housing	1
?	769 007 73	Plug	1
?	769 008 73	Adapter	1
?		Packing	2
?	769 009 73	Valve seat	1
?	769 010 73	Ball	1
?	769 011 73	Ball retainer	1
?	764 137 73	Adapter	1
?		O-ring	1
?	769 012 73	Pipe	1
?	769 013 73	Adapter	1
?		Cotter pin	2
?	769 014 73	Rod	1
?	769 015 73	Adapter	1
?	769 010 73	Ball	1
?	769 016 73	Ball	1
?	769 017 73	Pin	1
?	769 018 73	Piston assy.	1
?		O-ring	1
?	769 019 73	Cylinder barrel	1
?		Circlip	1
?		Valve guide	1
?	769 020 73	Piston rod, set	1
?		Cotter pin	1
?	769 021 73	Retaining ring	1
?	769 022 73	Valve	1
?	769 023 73	Valve seat	1
?	769 024 73	Piston nut	1
?	769 025 73	End pipe	1
?	500 848 98	Nut	4
?		Adapter	1
?		Plug	2
?		Distance rod	4
?	769 026 73	Repair kit to fig-no. 05 conist. of fig-nos. 16-19,23, 28,31,38,40,41,43	1
?	798 191 73	Seal kit to fig-no. 02	1
?			-2
?			-2
