JUNCTION BOX | PC3000-6E S/N 06361 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC3000-6E S/N 06361

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	974 197 40	Connection box assy.	1
?		Housing assy.	1
?		Inspection glass	1
?	313 503 99	Eyebolt	4
?	332 336 99	Hexagon nut	4
?		Expansion sleeve	6
?		Fit bolt	6
?		Angle	2
?		Lock washer	6
?	307 805 99	Hexagon head bolt	12
?	799 515 73	Switch-disconnector	1
?		Cu -bridge	1
?		Cu -bridge	1
?		Cu -bridge	1
?		Sealing	-2
?		Corrugated-head screw	40
?		Cover	1
?	769 224 73	Warning plate, Attention high voltage	2
?	769 223 73	Warning plate	2
?		Cover	1
?	307 777 99	Hexagon head bolt	6
?		Lock washer	16
?		Washer	18
?		Connecting bar	3
?	765 275 73	Support insulator	6
?	307 779 99	Hexagon head bolt	13
?		Spacer	3
?		Lock washer	6
?	307 825 99	Hexagon head bolt	6
?	512 467 98	Hexagon nut	9
?		Ground contact wire	6
?		Hexagon nut	6
?		Express-voltage discharger	3
?		Spring washer	9
?		Washer	11
?		Connecting bar (ground)	1
?		PE- support	2
?	307 823 99	Hexagon head bolt	2
?	512 466 98	Hexagon nut	2
?		Spacer	1
?		Plug	6
?		Brazen nut	3
?		Ground bolt	1
?		Heater	1
?		Lock washer	2
?		Head camp bolt	2
?	764 584 73	Safety switch	2
?		Hexagon head bolt	4
?		Lock washer	12
?		Hexagon nut	12
?		Ground wire	1
?		Pin	3
?		Lock	1
?		Pin	2
?		Bolt	2
?		Hexagon nut	4
?		Spring washer	4
?	798 644 73	Actuation	2
?		carriage bolt	4
?		Head camp bolt	2
?		Lock	1
?		Hexagon nut	2
?		Washer	2
?		Adapter	2
?	790 248 73	Cover box	1
?		Lock washer	10
?		Hexagon head bolt	4
?		Tube Clamp	1
?		Lever	1
?		Sealing	1
?		Hexagon nut	8
?		Flange for cable union	1
?		Cable union	2
?		Plate	1
?		Cable channel	-2
?		Hexagon head bolt	4
?		Hexagon nut	12
?		Hexagon head bolt	12
?		Cable channel	-2
?	356 265 40	Fixed of terminal	4
?		Conductor	1
?	794 158 73	Express-voltage discharger	1
?	794 730 73	Hexagon head bolt	4
?		Hexagon nut	4
?		Plate	1
?		Through clamp	8
?		Cross connection link	3
?		Ground terminal	5
?	795 572 73	Heat band	-2
?		Shield plate	1
?		Hexagon nut	4
?	790 249 73	Cover	1
