AIR CONDITIONING UNIT | PC3000-6 S/N 06369 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC3000-6 S/N 06369

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	942 067 40	Air Conditioning Unit assy.	1
?	794 712 73	Condenser unit assy.	1
?	794 432 73	Element drier	1
?	794 433 73	Collector bottle	1
?	796 581 73	Pressure control valve 30bar	-2
?	794 706 73	Inspection glass	1
?	794 708 73	Check valve	1
?	794 707 73	Double nut	1
?	794 994 73	High pressure switch	1
?	765 320 73	Clamp	2
?	794 434 73	Check valve	1
?	794 709 73	Ventilator	2
?	794 437 73	Hose assy.	1
?	794 438 73	Hose assy.	1
?	794 439 73	Hose assy.	1
?	794 440 73	Hose assy.	1
?	794 441 73	Pipe assy. 7/8	1
?	794 442 73	Pipe assy. 3/4	1
?	794 443 73	Elbow union	1
?	794 444 73	Elbow union	1
?	794 445 73	Elbow union	1
?	502 631 98	Pair of clamps	1
?	533 989 99	Weld on plate	1
?	307 737 99	Bolt	2
?	340 506 99	Washer	4
?	512 863 98	Pair of clamps	1
?	533 986 99	Weld on plate	1
?	307 736 99	Bolt	2
?	655 730 40	Hose DN13	-2
?	374 923 99	Clamp	5
?	795 001 73	Valve	1
?	794 759 73	Blower motor	1
?	794 760 73	Blower Wheel	1
?	794 761 73	Expansions valve	1
?	794 762 73	Low pressure switch	1
?	797 412 73	Air nozzle	6
?	797 413 73	Retaining ring for air nozzle	6
?	794 764 73	Air nozzle	4
?	765 159 73	Relay base	6
?	794 765 73	Relay 24V	6
?	794 766 73	Thermostat	1
?	765 305 73	Fuse box	2
?	765 306 73	Fuse 15A	1
?	769 120 73	Terminal	1
?	765 702 73	Fuse 10A	1
?	765 703 73	Fuse 20A	3
?	794 767 73	Line	1
?	798 413 73	Junction box cpl.	1
?	797 727 73	Evaporator	1
?	797 435 73	Control section	1
?	794 711 73	Temperatur sensor	1
?	794 713 73	Condenser unit -Liquid	1
?	794 920 73	Speed controller	1
?	500 942 98	Pair of clamps	1
?	511 856 98	Cover plate	1
?	308 538 99	Bolt	2
?	799 774 73	Screwed socket	1
?	215 809 99	Pipe	-2
?	907 203 40	Union	1
?	064 172 40	Nut	1
?	796 318 73	Filter mat	1
?	796 579 73	Drain pan	1
?	796 683 73	Plug connector24ts	1
?	796 684 73	Strain relief	1
?	796 685 73	Connector male	17
?	798 192 73	Bearing Housing kit	1
?	797 526 73	Harness cpl. incl. Item 52	1
?	799 939 73	Blower Housing	1
