AFE78-AL 930E-5 S/N A40139 - A40140 MOGALAKWENA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	EL7264	BRACKET	1
?	EL7260	TUBE	1
?	EH3195	CLAMP	1
?	EL0668	BRACKET	1
?	XB8739	BRACKET	1
?	EL7257	PLATE, BENT	1
?	EL2377	PLATE, BENT	1
?	EG6540	GASKET	1
?	EL0049	TUBE	1
?	EL7262	TUBE	1
?	EG6269	HOSE	6
?	F4037	FITTING, PIPE	1
?	WB1196	CLAMP, HYDRA ZORB	1
?	WB1088	CLAMP, T-BOLT	8
?	C5771	PLUG, PIPE - 1/2"	1
?	PC3031	CAPSCREW - M12 X 1.75 X 100	1
?	MM0605	CAPSCREW - M10 X 1.50 X 25	2
?	MM0607	CAPSCREW - M10 X 1.50 X 35	7
?	MM0471	LOCKWASHER - M10	5
?	MM0713	FLAT WASHER, HARDENED - M10	6
?	MM0178	NUT - M10 X 1.50	1
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	2
?	TG5720	CAPSCREW - 3/8" - 16NC X 1"	2
?	C1603	CAPSCREW - 3/8" - 16NC X 1 1/4"	4
?	TC1231	LOCKWASHER - 3/8"	9
?	TR4436	FLAT WASHER, HARDENED - 3/8"	5

Komatsu AFE78-AL 930E-5 S/N A40139 - A40140 MOGALAKWENA parts catalog PDF

RADIATOR PIPING 2/4 (65155) in AFE78-AL 930E-5 S/N A40139 - A40140 MOGALAKWENA. Diagram image and parts list.
