AFE78-AL 930E-5 S/N A40139 - A40140 MOGALAKWENA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	PB7929	PLUG, BUTTON	5
?	VM3655	BUSHING, CONDULET	8
?	VZ1369	LOCKNUT, CONDULET - 1"	8
?	VC1387	CAPSCREW - 1/2" - 13NC X 1"	4
?	TR5445	LOCKWASHER - 1/2"	4
?	TR6008	FLAT WASHER - 1/2"	4
?	VZ2686	STAND-OFF, INSULATED	2
?	EJ7758	ROD, THREADED - M6 X 1.00 X 50	2
?	MM0459	FLAT WASHER - M6	2
?	MM0469	LOCKWASHER - M6	2
?	MM0176	NUT - M6 X 1.00	2
?	EJ5576	CLAMP ASSEMBLY	2
?	WB3097	CLAMP, CUSHIONED - 1/2"	1
?	MM0178	NUT - M10 X 1.50	2
?	MM0471	LOCKWASHER - M10	2
?	MM0461	FLAT WASHER - M10	2
?	XB3583	BUS BAR	1
?	WB1301	CLAMP, CUSHIONED - 1/4"	1

Komatsu AFE78-AL 930E-5 S/N A40139 - A40140 MOGALAKWENA parts catalog PDF

BATTERY BOX ASSEMBLY 7/7 58F-54-20972 (64993) in AFE78-AL 930E-5 S/N A40139 - A40140 MOGALAKWENA. Diagram image and parts list.
