WHEEL MOTOR 4/8 58E-22-00413 | AFE77-AT 830E-5 S/N A50114 GOONYELLA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE77-AT 830E-5 S/N A50114 GOONYELLA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-22-00280	PINION & GEAR ASSEMBLY	3
?	VE4513	RING	3
?	VE4232	CAP, BEARING	3
?	VE8879	CAPSCREW - 1/2" - 13NC X 2"	18
?	VE5185	FLAT WASHER - 1/2"	51
?	BF3896	WIRE	-1
?	XA4271	BEARING, ROLLER	3
?	58E-22-00380	SLEEVE	3
?	VE8234	COLLAR	3
?	VE8233	CAP, BEARING	3
?	58E-22-00370	BEARING, ROLLER	1
?	VE4496	NUT	3
?	VE4497	LOCKWASHER	3
?	58E-22-00640	SHAFT & RING GEAR ASSEMBLY	1
?	58E-22-00440	SEAL, HOUSING (1)	1
?	BF3900	CAPSCREW - 1/2" - 13NC X 1 1/4"	24
?	BF2113	COUPLING	2
?	58E-22-00750	TUBE	2
?	BF2114	CLAMP, HOSE	4
?	VE4548	RING, DRIVE	1
?	BF3863	CAPSCREW - 1/2" - 13NC X 4"	1
?	XA2866	FRAME, HEAD	1
?	VE1273	RING, SEAL (1)	1
?	VE3035	CEMENT - 1 QUART	-1
?	VE4518	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	VE0756	RING (1)	1
?	58D-98-00300	SEAL, OIL (1)	2
?	VE0662	BAND, WEAR (1)	2
?	58E-22-00580	PACKING, FELT (1)	1
?	VE4236	SEAL (1)	1
?	VE4235	BAND, WEAR (1)	1
?	58E-22-00470	SEAL	2
?	VE4737	CLAMP	2
?	VE4536	COLLAR	1
?	BF2112	CAP, BEARING	1
?	VJ9656	ADHESIVE, RTV	-1
?	XA2867	BEARING, ROLLER	1
?	XA4276	HOUSING, BEARING	1
?	VE7207	COLLAR	1
?	VE7212	SEAL, V-RING (1)	1
?	BF1660	SEAL, LIP (1)	1
?	58E-WM-AK160	NOTE: (1) INCLUDED IN 58E-WM-AK160 WHEEL MOTOR	-1
?		OVERHAUL KIT.	-1
