SPINDLE, HUB AND BRAKE ASSEMBLY 2/2 58F-32-50070 | AFE78-BD 930E-5 S/N A40180 THEISS

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE78-BD 930E-5 S/N A40180 THEISS

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	EH7195	O-RING (1)	1
?	EJ7475	GEAR, SPEED SENSOR	1
?	58F-32-00202	SPINDLE	1
?	PC3059	BEARING ASSEMBLY, INNER (1)	1
?	562-22-32290	PIN (1)	2
?	ED3772	SPACER, BEARING	1
?	EH7194	O-RING (1)	1
?	EH7196	O-RING (1)	1
?	ED3775	ADAPTER, BRAKE	1
?	58F-32-50010	FRONT BRAKE ASSEMBLY (SEE INDEX)	1	65352
?	569-33-81241	ADAPTER	1
?	58C-32-00452	TANK, CATCHMENT	1
?	07002-52034	O-RING (1)	1
?	PC0651	SEAL ASSEMBLY (2)	1
?	PC1431	SEAL, OIL (1)/(2)	1
?	58F-32-40030	CARRIER, SEAL	1
?	58F-32-40051	BRACKET, MOUNTING	6
?	58F-32-00151	CARRIER, FLOATING SEAL	1
?	58F-32-00170	SEAL ASSEMBLY (1)	1
?	58F-32-00161	CARRIER, FLOATING SEAL	1
?	WA4780	PLUG, O-RING	2
?	58F-22-00850	VENT, BREATHER (1)	2
?	58F-32-00180	O-RING (1)	1
?	07000-52018	O-RING (1)	1
?	EH7193	O-RING (1)	1
?	D2930	CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4"	6
?	C1612	CAPSCREW - 1/2" - 13NC X 1"	12
?	C1613	CAPSCREW - 1/2" - 13NC X 1 1/4"	4
?	DF6928	CAPSCREW - 1/2" - 13NC X 1 3/4"	16
?	WA0360	FLAT WASHER, HARDENED - 1/2"	28
?	WA5669	CAPSCREW, 12 PT - 1 1/4" - 12NF X 3 1/2"	57
?	WB1231	CAPSCREW - 1 1/4" - 12NF X 8"	32
?	58B-09-50080	FLAT WASHER, HARDENED - 1 1/4"	75
?	58F-SM-AK060	NOTE: (1) INCLUDED IN 58F-SM-AK060 SPINDLE	-1
?		MAINTENANCE KIT. BALANCE OF PARTS ON PREVIOUS FIGURE.	-1
?	58F-BK-AK070	(2) INCLUDED IN 58F-BK-AK070 FRONT BRAKE	-1
?		SEAL KIT.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1
