Diagram image 1 of 2

PC3000-6 S/N 06381

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

PC3000-6 S/N 06381

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	768 047 73	Spindle	1
?	768 048 73	Support ring	1
?	768 049 73	Ring gear	1
?	768 050 73	Ring gear	1
?	792 118 73	Cover	1
?	768 409 73	Planet carrier	1
?	768 053 73	Planet carrier	1
?	768 054 73	Planet carrier	1
?	790 493 73	Planetary, is only deliverable as set amount (=5 pieces)	5
?		Planetery is no more available seperatly	-2
?	768 056 73	Planetary, is only deliverable as set amount (=3 pieces)	3
?		Planetery is no more available seperatly	-2
?	768 058 73	Planetary, is only deliverable as set amount (=5 pieces)	5
?		Planetery is no more available seperatly	-2
?	768 059 73	Sun gear	1
?	768 060 73	Sun gear	1
?	768 061 73	Sun gear shaft	1
?	768 062 73	Input shaft	1
?	768 063 73	Spur wheel	1
?	768 064 73	Shaft nut	1
?	768 065 73	Coupler	1
?	768 066 73	Seal ring	1
?	768 067 73	Disc	1
?	768 068 73	Housing washer	1
?	768 069 73	Disc	1
?	768 070 73	Locating ring	1
?	768 071 73	Coupler	1
?	792 119 73	Housing cpl. (Housing, H.flange,pin and bolt)	1
?	780 890 73	Ring	1
?	767 928 73	Tapered roller bearing	2
?	790 490 73	Cylindrical roller bearing	5
?	515 022 98	Cylindrical roller bearing	3
?	515 023 98	Cylindrical roller bearing	10
?	360 530 99	Ball bearing	2
?	515 024 98	Cylindrical roller bearing	1
?	515 025 98	Cylindrical roller bearing	1
?	360 532 99	Ball bearing	1
?	768 074 73	Locating ring	6
?	768 075 73	Locating ring	10
?	790 491 73	Face seal	1
?	790 494 73	Radial shaft seal ring	2
?	366 424 99	Radial shaft seal ring	2
?	514 132 98	Bolt	17
?	515 027 98	Bolt	30
?	319 286 99	Bolt	24
?	319 157 99	Bolt	60
?	509 170 98	Hex head bolt	12
?	308 606 99	Bolt	48
?	342 686 99	Circlip	1
?	342 684 99	Circlip	1
?	342 701 99	Circlip	1
?	342 672 99	Circlip	1
?	510 157 98	Circlip	5
?	342 685 99	Circlip	6
?	342 597 99	Circlip	1
?	342 560 99	Circlip	1
?	342 569 99	Circlip	2
?	342 572 99	Circlip	3
?	342 596 99	Circlip	1
?	342 555 99	Circlip	5
?	342 576 99	Circlip	5
?	504 251 98	O-ring	1
?	507 749 98	O-ring	2
?	972 161 00	O-ring	1
?	768 412 73	Chord ca. 2,6 m	-2
?	082 611 00	Chord ca. 2,36 m	-2
?	313 460 99	Plug	6
?	339 967 99	Seal ring	6
?	313 398 99	Plug	1
?	340 294 99	Seal ring	1
?	313 394 99	Plug	1
?	339 983 99	Seal ring	1
?	768 072 73		1
?	768 077 73	Disc	1
?	792 122 73	Disc	1
?	082 821 00	O-ring	1
?	806 590 73	Cover	1
?	307 754 99	Bolt	4
?	994 816 40	Drive gear box	1
?		Brake	1	991-0454a
?	790 495 73	Seal kit consist. of fig.nos. 20,43-45,75-77,82,84,86,91	1
?	790 496 73	Bearing kit consist. of fig.nos. 18,30-37,87	1

Komatsu PC3000-6 S/N 06381 parts catalog PDF

DRIVE GEAR BOX (991-1555) in PC3000-6 S/N 06381. Diagram image and parts list.
