PC3000-6 S/N 06382

Komatsu parts book diagram for PC3000-6 S/N 06382: BLEED-OFF VALVE, PRE-CONTROLLED

? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	906 861 40	Bleed-off valve, pre-controlled assy. without pressure adjustment	-2
	?		Fial resetting after mounting required	-2
	?	356 197 40	Valve, pre-controlled assy. 150bar	-2
	?	356 198 40	Valve, pre-controlled assy. 350bar	-2
	?	324 559 40	Valve, pre-controlled assy. 125bar	-2
	?	414 238 40	Valve, pre-controlled assy. 180bar	-2
	?	414 239 40	Valve, pre-controlled assy. 190bar	-2
	?	655 571 40	Valve, pre-controlled assy. 310bar	-2
	?	906 711 40	Valve, pre-controlled assy. 280bar	-2
	?	414 967 40	Valve, pre-controlled assy. 330bar	-2
	?	621 732 40	Valve, pre-controlled assy. 320bar	-2
	?		Pressure relief valve	1		991-1446a
	?	368 097 40	Support ring	2
	?	519 254 98	O-ring	2
	?	799 756 73	Seal kit to fig-no: 02	1

Komatsu PC3000-6 S/N 06382 parts catalog PDF

BLEED-OFF VALVE, PRE-CONTROLLED (090-0359a) in PC3000-6 S/N 06382. Diagram image and parts list.
