AFE78-BX 930E-5 S/N A40274 - A40276,A40291 MARIGOLD

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	MM0469	LOCKWASHER - M6	1
?	MM0471	LOCKWASHER - M10	1
?	WB1304	CLAMP, CUSHIONED - 9/16"	1
?	MM0470	LOCKWASHER - M8	3
?	MM0460	FLAT WASHER - M8	3
?	MM0461	FLAT WASHER - M10	1
?	MM0178	NUT - M10 X 1.50	1
?	MM0594	CAPSCREW - M8 X 1.25 X 25	3
?	XC2401	PLATE, INSULATED	1
?	MM0472	LOCKWASHER - M12	8
?	CH5756	CABLE, BLACK	1
?	CH5755	CABLE, BLACK	1
?	VM3655	BUSHING, CONDULET	4
?	VZ1369	LOCKNUT, CONDULET - 1"	4
?	EJ3891	CLAMP ASSEMBLY	1
?	MM0179	NUT - M12 X 1.75	8
?	MM0459	FLAT WASHER - M6	1
?	MM0176	NUT - M6 X 1.00	1
?	EJ7758	ROD, THREADED - M6 X 1.00 X 50	1
?	MM0619	CAPSCREW - M12 X 1.75 X 35	8
?	MM0462	FLAT WASHER - M12	16

Komatsu AFE78-BX 930E-5 S/N A40274 - A40276,A40291 MARIGOLD parts catalog PDF

BATTERY BOX ASSEMBLY 5/7 58F-54-20972 (64991) in AFE78-BX 930E-5 S/N A40274 - A40276,A40291 MARIGOLD. Diagram image and parts list.
