AFE78-BM 930E-5 S/N A40215 - A40218,A40225 - A40229 LOS BRONCES

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	VE9550	BEARING	1
?	VE9549	GASKET	1
?	VE9548	PLATE, VALVE - RH	1
?	BF1371	O-RING	1
?	BF3485	PLUG	1
?	VE9551	O-RING	1
?	VE9600	COVER, VALVE PLATE	1
?	VE9537	CAPSCREW	4
?	VE9601	CAPSCREW	4
?	XA0196	SEAL (1)	1
?	VE9588	CAP	1
?	VE9536	PLUG	1
?	58E-98-00050	O-RING (1)	1
?	VE9592	CAPSCREW	4
?	VE9615	O-RING (1)/(2)	1
?	VE9616	O-RING (2)	3
?	VE9617	O-RING (2)	1
?	58E-98-00370	CONTROL ASSEMBLY (2) (SEE INDEX)	1	62383
?	WB0499	FITTING, ELBOW - 90 DEG	1
?	58E-98-00000	NOTE: (1) INCLUDED IN 58E-98-00000 PUMP SEAL KIT.	-1
?	58C-98-00520	(2) INCLUDED IN 58C-98-00520 CONTROL ASSEMBLY KIT.	-1

Komatsu AFE78-BM 930E-5 S/N A40215 - A40218,A40225 - A40229 LOS BRONCES parts catalog PDF

STEERING PUMP HOUSING (REAR) 58C-60-00080 (68457) in AFE78-BM 930E-5 S/N A40215 - A40218,A40225 - A40229 LOS BRONCES. Diagram image and parts list.
