AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-50-01250	CYLINDER HEAD ASSEMBLY	1
?	58B-50-01260	HEAD	1
?	EL3415	QUILL ASSEMBLY	1
?	EL3414	QUILL	1
?	722187	POPPET, BALL	2
?	EB8590	PLUG	2
?	VM2202	PLUG, VENT	1
?	VZ2266	O-RING	1
?	VN9097	CAPSCREW - 1" - 8NC X 2 3/4"	24
?	WA0364	FLAT WASHER, HARDENED - 1"	24
?	WA0458	O-RING (1)	1
?	WA1458	RING, BACKUP (1)	1
?	58B-50-01450	SNAP RING	1
?	58B-50-01470	BEARING - 12 5/8" (1)	2
?	58B-50-01310	SEAL - 12 5/8" (1)	1
?	TY1503	SEAL (1)	1
?	58B-50-01280	RETAINER, BEARING	1
?	WA1627	CAPSCREW - 7/8" - 9NC X 2 1/2"	10
?	58B-50-01480	BEARING - 15 1/8" (1)	2
?	58B-50-01320	SEAL - 15 1/8" (1)	1
?	58B-50-01460	BEARING - 10 1/8" (1)	2
?	58B-50-01300	SEAL - 10 1/8" (1)	1
?	58B-50-01020	HOUSING	1
?	58B-50-01070	TUBE - 14 1/8"	1
?	58B-50-01120	TUBE - 14 1/8"	1
?	58B-50-01170	ROD, PIVOT	1
?	58B-50-01410	BEARING - 14 1/8" (1)	1
?	58B-50-01440	SEAL, BUFFER - 14 1/8" (1)	1
?	58B-50-01400	SEAL, ROD - 14 1/8" (1)	1
?	58B-50-01390	SEAL, WIPER - 14 1/8" (1)	1
?	58B-50-01380	BEARING - 11 3/8" (1)	1
?	58B-50-01430	SEAL, BUFFER - 11 3/8" (1)	1
?	58B-50-01370	SEAL, ROD - 11 3/8" (1)	1
?	58B-50-01360	SEAL, WIPER - 11 3/8" (1)	1
?	58B-50-01350	BEARING - 7 5/8" (1)	1
?	58B-50-01420	SEAL, BUFFER - 7 5/8" (1)	1
?	58B-50-01340	SEAL, ROD - 7 5/8" (1)	1
?	58B-50-01330	SEAL, WIPER - 7 5/8" (1)	1
?	58B-50-01560	PLATE	1
?	58B-50-01490	SNAP RING	1
?	WA1443	RING, BACKUP (1)	2
?	WA0443	O-RING (1)	1
?	VN9350	RING, RETAINING	2
?	VL4293	BUSHING, BALL	1
?	SV5921	RING, RETAINING	2
?	PC1291	BEARING, SPHERICAL	1
?	WB1241	KIT, SHIPPING PLATE	1
?	WB1239	KIT, SHIPPING PLATE	1
?	58B-HC-AK020	NOTE: (1) INCLUDED IN 58B-HC-AK020 REBUILD KIT.	-1

Komatsu AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE parts catalog PDF

HOIST CYLINDER ASSEMBLY W/ BEARINGS 58B-50-01000 (69764) in AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE. Diagram image and parts list.
