AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	BF2446	ELBOW	2
?	LA0605	UNLOADER, SAFETY	1
?	58F-98-40750	PLUG, PIPE	1
?	58F-98-40090	COVER	1
?	LA1187	VALVE, CHECK (SEE INDEX)	1	60398
?	58F-98-40240	LUBE PUMP ASSEMBLY (SEE INDEX)	1	69500
?	58F-98-40150	SCREW	4
?	58F-98-40160	LOCKWASHER	4
?	58F-98-40170	GASKET	1
?	BF5425	ELBOW	1
?	XA1983	HOSE	1
?	58F-98-40130	WRAP, SPIRAL	1
?	58F-98-40030	HOSE	1
?	BF5426	HOSE, VENT	1
?	58F-98-40220	COVER	1
?	58F-98-40230	GASKET	1
?	58F-98-40200	SCREW	5
?	58F-98-40210	LOCKWASHER	5
?	BF5439	CAPSCREW - 3/8" - 16NC X 1 1/4"	6
?	LA1212	LOCKWASHER	8
?	BF5449	ELBOW	1
?	XA1988	GASKET	1
?	58F-98-40180	NUT	1
?	58F-98-40190	TUBE, VENT	1
?	BF5440	GASKET	1
?	58F-98-40100	PLUG, PIPE	1
?	58F-98-40120	PLUG, PIPE	1
?	58F-98-40050	TUBE, FILL	1
?	58F-98-40110	CONTAINER ASSEMBLY	1
?	58F-98-40010	ELBOW	3
?	58F-98-40020	ADAPTER	1
?	58F-98-40060	ADAPTER, ELBOW	1
?	58F-98-40760	CAPSCREW	1
?	58F-98-40770	GASKET	1
?	58F-98-40780	LOCKWASHER	1
?	58F-98-40790	NUT	1
?	58F-98-40070	EYE BOLT	2
?	LA0912	VALVE, VENT (SEE INDEX)	1	60397
?	BF5423	CAPSCREW - 5/16" - 18NC X 3/4"	2
?	BF5084	LOCKWASHER	2
?	58F-98-40080	NUT, HEX	2
?	58F-98-40140	PLUG, PIPE	1
?	58F-98-40590	NIPPLE	1

Komatsu AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE parts catalog PDF

LUBE PUMP/CONTAINER ASSEMBLY 58F-98-40250 (43900) in AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE. Diagram image and parts list.
