AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	MM0604	CAPSCREW - M10 X 1.50 X 20	4
?	EM1398	SPACER	1
?	WB3097	CLAMP, CUSHIONED - 1/2"	9
?	WB1304	CLAMP, CUSHIONED - 9/16"	10
?	MM0461	FLAT WASHER - M10	7
?	WB1306	CLAMP, CUSHIONED - 2"	1
?	WB3922	CLAMP, CUSHIONED - 11/16"	1
?	MM0471	LOCKWASHER - M10	7
?	MM0178	NUT - M10 X 1.50	26
?	EJ3891	CLAMP ASSEMBLY	16
?	MM0460	FLAT WASHER - M8	8
?	MM0469	LOCKWASHER - M6	12
?	MM0176	NUT - M6 X 1.00	8
?	EL1939	ROD, THREADED	8
?	MM0606	CAPSCREW - M10 X 1.50 X 30	2
?	WB3098	CLAMP, CUSHIONED - 3/8"	8
?	58C-09-10020	NUT - M20 X 2.50	8
?	426-06-11570	BRACKET	2
?	58D-90-00700	CLAMP, CUSHIONED - 7/16"	16
?	TY8375	SPACER	2
?	TC1233	NUT - 3/8" - 16NC	4
?	TR4436	FLAT WASHER, HARDENED - 3/8"	6
?	58E-09-00500	LOCKWASHER - M20	8
?	WB1193	CAPSCREW, 12 PT - M20 X 2.50 X 90	2
?	58B-09-00720	CAPSCREW - M20 X 2.50 X 80	8
?	01643-32060	FLAT WASHER, HARDENED - M20	16
?	58B-06-20443	HARNESS, WIRING - ENGINE EXTERNAL	1
?	MM0475	LOCKWASHER - M20	2
?	WB1300	CLAMP, CUSHIONED - 5/8"	1
?	WB1303	CLAMP, CUSHIONED - 3/4"	5
?	EL7273	SPACER	1

Komatsu AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE parts catalog PDF

CRANKING MOTOR WIRING 1/2 (64912) in AFE75-AM 980E-5 S/N A50142 - A50143 SPENCE. Diagram image and parts list.
