281-09-11110
|
O-RING (1) |
1 |
|
|
|
|
? |
58E-32-50530
|
GEAR, SPEED SENSOR |
1 |
|
|
|
|
? |
58E-32-50430
|
SPINDLE |
1 |
|
|
|
|
? |
PC0003
|
CUP, BEARING |
1 |
|
|
|
|
? |
562-22-32290
|
PIN (1) |
2 |
|
|
|
|
? |
EB1715
|
SPACER |
1 |
|
|
|
|
? |
58E-32-50410
|
FRONT BRAKE ASSEMBLY (SEE INDEX) |
1 |
|
48742 |
|
|
? |
58E-32-50420
|
TANK, CATCHMENT (1) |
1 |
|
|
|
|
? |
562-33-00014
|
SEAL ASSEMBLY (2) |
1 |
|
|
|
|
? |
562-33-11941
|
SEAL (1)/(2) |
1 |
|
|
|
|
? |
58E-32-50460
|
CARRIER, SEAL |
1 |
|
|
|
|
? |
58E-32-50750
|
O-RING |
1 |
|
|
|
|
? |
58E-32-50700
|
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
? |
H8402
|
PLUG - 3/8" |
1 |
|
|
|
|
? |
VN9132
|
CAPSCREW - 1 1/8" - 8NC X 3 3/4" |
32 |
|
|
|
|
? |
58E-09-50060
|
CAPSCREW - 1 1/8" - 12NF X 6.5" |
32 |
|
|
|
|
? |
58B-09-50080
|
FLAT WASHER, HARDENED - 1 1/4" |
32 |
|
|
|
|
? |
58E-09-50070
|
FLAT WASHER, HARDENED - 1/8" |
32 |
|
|
|
|
? |
PC1696
|
CONE, BEARING |
1 |
|
|
|
|
? |
58E-09-50040
|
FITTING, ELBOW - 90 DEG |
1 |
|
|
|
|
? |
58E-09-50050
|
FITTING STRAIGHT |
1 |
|
|
|
|
? |
58E-32-50590
|
HOSE |
1 |
|
|
|
|
? |
HC0908
|
CLAMP, WORM DRIVE |
2 |
|
|
|
|
? |
WA4780
|
PLUG, O-RING |
1 |
|
|
|
|
? |
WB3205
|
NUT, FLANGED - 1" - 8NC |
3 |
|
|
|
|
? |
TY2148
|
FLAT WASHER, HARDENED - 1" |
9 |
|
|
|
|
? |
58E-32-50800
|
BRACKET ASSEMBLY |
3 |
|
|
|
|
? |
C1643
|
CAPSCREW - 3/4" - 10NC X 1 3/4" |
3 |
|
|
|
|
? |
WA0362
|
FLAT WASHER - 3/4" |
3 |
|
|
|
|
? |
58F-22-00850
|
VENT, BREATHER (1) |
2 |
|
|
|
|
? |
58F-SM-AK060
|
NOTE: (1) INCLUDED IN 58F-SM-AK060 SPINDLE |
-1 |
|
|
|
|
? |
|
MAINTENANCE KIT. BALANCE OF PARTS ON PREVIOUS FIGURE. |
-1 |
|
|
|
|
? |
58F-BK-AK070
|
(2) INCLUDED IN 58F-BK-AK070 FRONT BRAKE |
-1 |
|
|
|
|
? |
|
SEAL KIT. |
-1 |
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
-1 |
|
|
