AFE78-CH 930E-5 S/N A40303 - A40306 BARRICK LUMWANA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	WB3092	CLAMP, CUSHIONED - 7/8"	29
?	MM0605	CAPSCREW - M10 X 1.50 X 25	7
?	MM0461	FLAT WASHER - M10	28
?	MM0471	LOCKWASHER - M10	28
?	MM0178	NUT - M10 X 1.50	28
?	WB1303	CLAMP, CUSHIONED - 3/4"	1
?	EM1393	SPACER	7
?	MM0606	CAPSCREW - M10 X 1.50 X 30	1
?	VD6174	CLAMP, U-BOLT	2
?	EM8447	PLATE, BENT	7
?	HC0908	CLAMP, WORM DRIVE	4
?	58E-03-01200	VALVE, BALL	1
?	58E-03-01190	ADAPTER, HOSE	1
?	PC1780	ADAPTER	2
?	58E-54-17482	HOSE, HEATER	1
?	58F-54-11090	HOSE, HEATER	1
?	WA6618	CLAMP TUBE	1
?	KC1255	CLAMP	2

Komatsu AFE78-CH 930E-5 S/N A40303 - A40306 BARRICK LUMWANA parts catalog PDF

HEATER HOSE INSTALLATION 1/2 (68075) in AFE78-CH 930E-5 S/N A40303 - A40306 BARRICK LUMWANA. Diagram image and parts list.
