AFE78-CH 930E-5 S/N A40303 - A40306 BARRICK LUMWANA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58B-06-02580	CONNECTOR, FUSE HOLDER	1
?	MM0595	CAPSCREW - M8 X 1.25 X 30	8
?	MM0714	FLAT WASHER, HARDENED - M12	4
?	MM0470	LOCKWASHER - M8	10
?	MM0460	FLAT WASHER - M8	10
?	58F-54-20910	PLATE	1
?	PB5993	COVER	2
?	MM0594	CAPSCREW - M8 X 1.25 X 25	2
?	58F-06-02901	CABLE, RED	1
?	MM0472	LOCKWASHER - M12	8
?	MM0462	FLAT WASHER - M12	12
?	58F-06-10720	BUS BAR	1
?	VZ2686	STAND-OFF, INSULATED	2
?	TR6008	FLAT WASHER - 1/2"	4
?	TR5445	LOCKWASHER - 1/2"	8
?	MM0179	NUT - M12 X 1.75	8
?	VC1387	CAPSCREW - 1/2" - 13NC X 1"	4
?	MM0619	CAPSCREW - M12 X 1.75 X 35	8
?	MM0177	NUT - M8 X 1.25	8
?	58F-06-50520	RECEPTACLE, AUXILIARY START	1
?	58F-06-50530	RECEPTACLE, AUXILIARY START	1
?	EJ7781	GASKET, RUBBER	2

Komatsu AFE78-CH 930E-5 S/N A40303 - A40306 BARRICK LUMWANA parts catalog PDF

BATTERY BOX ASSEMBLY 6/7 58F-54-20972 (64992) in AFE78-CH 930E-5 S/N A40303 - A40306 BARRICK LUMWANA. Diagram image and parts list.
