AFE78-CB 930E-5 S/N A40282 - A40283 BOLIDEN

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58F-54-02434	DECK, RH	1
?	58D-80-00250	BRACKET	1
?	EC7589	PLATE	1
?	58E-09-30010	CAPSCREW - M20 X 2.50 X 45	4
?	58E-09-30000	FLAT WASHER, HARDENED - M20	4
?	D104556	BUMPER	1
?	58E-09-00930	FLAT WASHER - 9/16"	1
?	TR6643	NUT - 1/2" - 13NC	1
?	EC7594	FLAT WASHER, HARDENED - 3/8"	8
?	58F-09-00510	NUT - M20 X 2.50	8
?	58B-09-00740	CAPSCREW - M20 X 2.50 X 110	8
?	EG9144	SPACER	8
?	58D-80-00260	CAPSCREW - M16 X 2.00 X 105	1
?	58C-09-00000	LOCKNUT - M16 X 2.00	1

Komatsu AFE78-CB 930E-5 S/N A40282 - A40283 BOLIDEN parts catalog PDF

RH DECK INSTALLATION (65146) in AFE78-CB 930E-5 S/N A40282 - A40283 BOLIDEN. Diagram image and parts list.
