AFE92-A 980E-5SE S/N A60001 - A60010 KMMP

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	58B-06-07820	STATOR ASSEMBLY (SEE INDEX)	1	48304
?	58B-06-05450	ROTOR ASSEMBLY (SEE INDEX)	1	48303
?	GE1460	CAP, BEARING	1
?	GE1461	COLLAR	1
?	GE1462	BEARING	1
?	58B-06-02090	FLINGER, COLLAR ASSEMBLY	1
?	TV1918	CAPSCREW - 1/2" - 13NC X 1 3/4"	12
?	VE5185	FLAT WASHER - 1/2"	24
?	BF1660	SEAL, LIP	1
?	XA4500	FRAME HEAD	1
?	XA4511	SEAL, V-RING	1
?	GE1465	FRAME HEAD	1
?	GE1467	CAP, BEARING SEAL	1
?	GE1468	CAP, BEARING SEAL	1
?	GE1470	COLLAR	1
?	GE1471	COLLAR	1
?	GE1472	BEARING, ROLLER	1
?	VE4518	CAPSCREW - 1/2" - 13NC X 1 1/2"	12
?	GE1473	SEAL, LIP	1
?	XA4512	HOUSING, BEARING	1
?	XA4513	FLINGER	1
?	XA4514	SEAL	1
?	VS6852	CAPSCREW - 5/8" - 11NC X 2 1/2"	15
?	GE1474	CAPSCREW - 5/8" - 11NC X 2 1/4"	12
?	XA4136	FLAT WASHER, HARDENED - 5/8"	27
?	58B-06-02080	DOWEL, PIN	1

Komatsu AFE92-A 980E-5SE S/N A60001 - A60010 KMMP parts catalog PDF

WHEEL MOTOR 1/2 58B-06-11150 (48301) in AFE92-A 980E-5SE S/N A60001 - A60010 KMMP. Diagram image and parts list.
