AFE92-A 980E-5SE S/N A60001 - A60010 KMMP

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-60-40000	DUAL RELAY VALVE	1
?	MM0618	CAPSCREW - M12 X 1.75 X 30	2
?	MM0462	FLAT WASHER - M12	2
?	58B-60-51390	HOSE	1
?	58F-60-41890	HOSE	1
?	WB0509	FITTING, ELBOW - 90 DEG	1
?	58B-60-10061	HOSE	1
?	WB0584	FITTING, STRAIGHT	2
?	58B-60-30960	HOSE	1
?	58B-60-01721	HOSE	1
?	WB0574	FITTING, STRAIGHT	1
?	WB3092	CLAMP, CUSHIONED - 7/8"	10
?	EM1393	SPACER	3
?	MM0178	NUT - M10 X 1.50	5
?	MM0471	LOCKWASHER - M10	7
?	MM0461	FLAT WASHER - M10	5
?	EM3586	SPACER	2
?	WB0593	FITTING, STRAIGHT	1
?	WB1308	CLAMP, CUSHIONED - 1 1/16"	3
?	XC2555	STUD - M10 X 1.50 X 60	2
?	MM0605	CAPSCREW - M10 X 1.50 X 25	2
?	MM0713	FLAT WASHER, HARDENED - M10	2
?	MM0472	LOCKWASHER - M12	2
?	58F-54-52130	PLATE, BENT - TOP	1
?	PB6769	COUPLING, MALE	2
?	162144	CAP, DUST	2
?	TL3995	O-RING	2
?	PC3009	FITTING, ELBOW	1
?	EM4587	ROD, THREADED	2

Komatsu AFE92-A 980E-5SE S/N A60001 - A60010 KMMP parts catalog PDF

FRONT BRAKE DUAL RELAY VALVE PIPING & INSTALLATION (49521) in AFE92-A 980E-5SE S/N A60001 - A60010 KMMP. Diagram image and parts list.
