PC4000-11 S/N 08312

Komatsu parts book diagram for PC4000-11 S/N 08312: PIN SEALING STEERING AND ROD

01 01 02 02 03 04 05 05 06 06 07 08 10 10 11 11 12 13 14 14 15 15 16 17 20 20 20 20

	#	Part Number	Partname	Quantity	Options	Reference
	01	62780840	SEAL FIXING ASSY.INCL. FIG-NOS. 30-32	2	vendorcode: KOMATSU \| visiblepartno: 62780840
	02	62782440	SEAL	2	vendorcode: KOMATSU \| visiblepartno: 62782440
	03		UPPER RING HALF	2	docwarecomment: *
	04		LOWER RING HALF	2	docwarecomment: *
	05	89090940	SEAL FIXINGFIG-NOS. 07, 08, 20	4	vendorcode: KOMATSU \| visiblepartno: 89090940
	06	65573340	SEAL RING	4	vendorcode: KOMATSU \| visiblepartno: 65573340
	07		UPPER RING HALF	2	docwarecomment: *
	08		LOWER RING HALF	2	docwarecomment: *
	10	90521640	SEAL FIXINGFIG-NOS. 12, 13, 20	2	vendorcode: KOMATSU \| visiblepartno: 90521640
	11	24709040	SEAL RING	2	vendorcode: KOMATSU \| visiblepartno: 24709040
	12		UPPER RING HALF	2	docwarecomment: *
	13		LOWER RING HALF	2	docwarecomment: *
	14	90075840	SEAL FIXING ASSY.INCL. FIG-NOS. 21-23	2	vendorcode: KOMATSU \| visiblepartno: 90075840
	15	65217440	SEAL	2	vendorcode: KOMATSU \| visiblepartno: 65217440
	16		UPPER RING HALF	2	docwarecomment: *
	17		LOWER RING HALF	2	docwarecomment: *
	20	50917098	BOLT	20	vendorcode: KOMATSU \| visiblepartno: 50917098
	\|$17			-1	docwarecomment: *

Komatsu PC4000-11 S/N 08312 parts catalog PDF

PIN SEALING STEERING AND ROD (355-4600) in PC4000-11 S/N 08312. Diagram image and parts list.
