PC4000-11 S/N 08312

Komatsu parts book diagram for PC4000-11 S/N 08312: POWER FRAME ARR.

01 02 03 04 05 06 07 11 15 15 15 16 16 17 18

	#	Part Number	Partname	Quantity	Options	Reference
	01	98180040	POWER FRAME	1	vendorcode: KOMATSU \| visiblepartno: 98180040
	02	95400040	LEAKAGE OIL TANK INCLUDED FIG NO. 05	1	vendorcode: KOMATSU \| visiblepartno: 95400040
	03	51073398	ANTI-FATIGUE SLEEVE	4	vendorcode: KOMATSU \| visiblepartno: 51073398
	04	30863599	BOLT	4	vendorcode: KOMATSU \| visiblepartno: 30863599
	05	99675040	TRAVERSE	1	vendorcode: KOMATSU \| visiblepartno: 99675040
	06	51712498	LOCK WASHER	6	vendorcode: KOMATSU \| visiblepartno: 51712498
	07	30784499	BOLT	6	vendorcode: KOMATSU \| visiblepartno: 30784499
	11	51536240	VALVE	1	vendorcode: KOMATSU \| visiblepartno: 51536240
	15	50673498	WASHER	28	vendorcode: KOMATSU \| visiblepartno: 50673498
	16	51591498	BOLT	6	vendorcode: KOMATSU \| visiblepartno: 51591498
	17	51953198	BOLT	22	vendorcode: KOMATSU \| visiblepartno: 51953198
	18	90737140	EDGE PROFILE	-1	docwarecomment: * \| vendorcode: KOMATSU \| visiblepartno: 90737140
	\|$12		BULKWARE, STATE LENGTH REQUIRED	-1

Komatsu PC4000-11 S/N 08312 parts catalog PDF

POWER FRAME ARR. (360-1200A) in PC4000-11 S/N 08312. Diagram image and parts list.
