AFE78-DJ 930E-5 S/N A40362 - A40363,A40374 KAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58F-32-50250	HUB ASSEMBLY	1
?	EH0826	STUD W/ HEAD (1)	57
?	EH7192	O-RING	1
?	EL2876	SHIM - .005"	3
?	EL2877	SHIM - .007"	4
?	EL2878	SHIM - .020"	6
?	58F-32-00221	COVER	1
?	WB1199	PLUG, MAGNETIC	1
?	EH7190	O-RING	1
?	XB7696	RETAINER, BEARING	1
?	58F-32-00370	BEARING ASSEMBLY, OUTER	1
?	ED3755	SHIM - .020"	54
?	ED3756	SHIM - .010"	6
?	PB7454	GAUGE, SIGHT	1
?	TH6916	VALVE, CHECK	1
?	58F-32-50040	COVER, DUST	1
?	58F-32-50050	PLUG, OIL SAMPLING	1
?	58F-80-20341	PLATE, DECAL	1
?	58F-80-20350	PLATE	1
?	WB3932	DECAL, PRESSURIZED FLUID	1
?	58C-09-00010	CAPSCREW - 1/4" - 20NC X 1/2"	6
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4"	2
?	WA0720	FLAT WASHER, HARDENED - 3/8"	2
?	C1614	CAPSCREW - 1/2" - 13NC X 1 1/2"	12
?	VN9065	CAPSCREW - 1/2" - 13NC X 2"	12
?	C1540	LOCKWASHER - 1/2"	12
?	WA0360	FLAT WASHER, HARDENED - 1/2"	28
?	TY2148	FLAT WASHER, HARDENED - 1"	8
?	VM8258	CAPSCREW - 1" - 8NC X 3 3/4"	8
?	58F-EP-AK741	NOTE: (1) INCLUDED IN 58F-EP-AK741 FRONT WHEEL GROUP	-1
?		HARDWARE KIT.	-1
?		(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.)	-1

Komatsu AFE78-DJ 930E-5 S/N A40362 - A40363,A40374 KAL parts catalog PDF

SPINDLE, HUB AND BRAKE ASSEMBLY 1/2 58F-32-50072 (69821) in AFE78-DJ 930E-5 S/N A40362 - A40363,A40374 KAL. Diagram image and parts list.
