SAA12V140E-7 S/N 900006-UP (For PC2000-11R)

1 2 3 4 5 6 7 8 8 5 5 8 4

#	Part Number	Partname	Quantity	Options
\|$0	6219-31-1100	Crankshaft Assembly	1	SN: 900125-UP
1		Crankshaft	1	SN: 900125-UP \| SCC: C1
2	6215-31-1140	Gear	1	SN: 900125-UP
3	04010-00728	Key	1	SN: 900125-UP
\|$4	6215-21-8011	Main Metal Assembly, No.1.2,3,5,6,7, Standard	6	SN: 900125-UP
\|$5	6215-29-8011	Main Metal Assembly, No.1.2,3,5,6,7, Undersize, 0.25mm	6	SN: 900125-UP
\|$6	6215-28-8011	Main Metal Assembly, No.1.2,3,5,6,7, Undersize, 0.50mm	6	SN: 900125-UP
\|$7	6215-27-8011	Main Metal Assembly, No.1.2,3,5,6,7, Undersize, 0.75mm	6	SN: 900125-UP
\|$8	6215-26-8011	Main Metal Assembly, No.1.2,3,5,6,7, Undersize, 1.00mm	6	SN: 900125-UP
4		Metal, Upper, Standard	6	SN: 900125-UP \| SCC: C1
\|$10		Metal, Upper, Undersize, 0.25mm	6	SN: 900125-UP \| SCC: C1
\|$11		Metal, Upper, Undersize, 0.50mm	6	SN: 900125-UP \| SCC: C1
\|$12		Metal, Upper, Undersize, 0.75mm	6	SN: 900125-UP \| SCC: C1
\|$13		Metal, Upper, Undersize, 1.00mm	6	SN: 900125-UP \| SCC: C1
5		Metal, Lower, Standard	6	SN: 900125-UP \| SCC: C1
\|$15		Metal, Lower, Undersize, 0.25mm	6	SN: 900125-UP \| SCC: C1
\|$16		Metal, Lower, Undersize, 0.50mm	6	SN: 900125-UP \| SCC: C1
\|$17		Metal, Lower, Undersize, 0.75mm	6	SN: 900125-UP \| SCC: C1
\|$18		Metal, Lower, Undersize, 1.00mm	6	SN: 900125-UP \| SCC: C1
\|$19	6215-21-8021	Main Metal Assembly, No.4, Standard	1	SN: 900125-UP
\|$20	6215-29-8021	Main Metal Assembly, No.4, Undersize, 0.25mm	1	SN: 900125-UP
\|$21	6215-28-8021	Main Metal Assembly, No.4, Undersize, 0.50mm	1	SN: 900125-UP
\|$22	6215-27-8021	Main Metal Assembly, No.4, Undersize, 0.75mm	1	SN: 900125-UP
\|$23	6215-26-8021	Main Metal Assembly, No.4, Undersize, 1.00mm	1	SN: 900125-UP
6		Metal, Upper, Standard	1	SN: 900125-UP \| SCC: C1
\|$25		Metal, Upper, Undersize, 0.25mm	1	SN: 900125-UP \| SCC: C1
\|$26		Metal, Upper, Undersize, 0.50mm	1	SN: 900125-UP \| SCC: C1
\|$27		Metal, Upper, Undersize, 0.75mm	1	SN: 900125-UP \| SCC: C1
\|$28		Metal, Upper, Undersize, 1.00mm	1	SN: 900125-UP \| SCC: C1
7		Metal, Lower, Standard	1	SN: 900125-UP \| SCC: C1
\|$30		Metal, Lower, Undersize, 0.25mm	1	SN: 900125-UP \| SCC: C1
\|$31		Metal, Lower, Undersize, 0.50mm	1	SN: 900125-UP \| SCC: C1
\|$32		Metal, Lower, Undersize, 0.75mm	1	SN: 900125-UP \| SCC: C1
\|$33		Metal, Lower, Undersize, 1.00mm	1	SN: 900125-UP \| SCC: C1
\|$34	6215-21-8050	Thrust Metal Assembly, Standard	1	SN: 900125-UP
\|$35	6215-29-8050	Thrust Metal Assembly, Undersize, 0.25mm	1	SN: 900125-UP
\|$36	6215-28-8050	Thrust Metal Assembly, Undersize, 0.50mm	1	SN: 900125-UP
\|$37	6215-27-8050	Thrust Metal Assembly, Undersize, 0.75mm	1	SN: 900125-UP
\|$38	6215-26-8050	Thrust Metal Assembly, Undersize, 1.00mm	1	SN: 900125-UP
8		Metal, Standard	3	SN: 900125-UP \| SCC: C1
\|$40		Metal, Undersize, 0.25mm	3	SN: 900125-UP \| SCC: C1
\|$41		Metal, Undersize, 0.50mm	3	SN: 900125-UP \| SCC: C1
\|$42		Metal, Undersize, 0.75mm	3	SN: 900125-UP \| SCC: C1
\|$43		Metal, Undersize, 1.00mm	3	SN: 900125-UP \| SCC: C1
\|$44		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu SAA12V140E-7 S/N 900006-UP (For PC2000-11R) parts catalog PDF

CRANKSHAFT, (#900125-) (A2310-002001) in SAA12V140E-7 S/N 900006-UP (For PC2000-11R). Diagram image and parts list.
