PC3385
|
GAUGE PANEL (SEE FIG 61325) |
1 |
|
61325 |
|
|
? |
PB8658
|
CAPSCREW - M6 X 1.00 X 30 |
10 |
|
|
|
|
? |
EK7947
|
LOUVER, RECTANGULAR |
2 |
|
|
|
|
? |
58E-54-04790
|
DASH MODULE, UPPER RH (1) (SEE FIG 43488) |
1 |
|
43488 |
|
|
? |
58F-54-00602
|
DASH MODULE, LOWER RH (1) (SEE FIG 49709) |
1 |
|
49709 |
|
|
? |
WB3295
|
DECAL, SHIFT SELECTOR |
1 |
|
|
|
|
? |
WB2490
|
DECAL, KEY SWITCH WARNING |
1 |
|
|
|
|
? |
DC9822
|
DRIVE SCREW |
8 |
|
|
|
|
? |
SM2648
|
PLATE, SEAL RETAINER - RH |
1 |
|
|
|
|
? |
SM2646
|
PLATE, SEAL RETAINER - LH |
1 |
|
|
|
|
? |
PB9829
|
CAPSCREW - M6 X 1.00 X 16 |
10 |
|
|
|
|
? |
TX7829
|
SEAL, STEERING COLUMN |
1 |
|
|
|
|
? |
58E-54-08490
|
DASH MODULE, LOWER LH (1) (SEE FIG 49027) |
1 |
|
49027 |
|
|
? |
EK8962
|
SEAL, LOWER MODULE |
2 |
|
|
|
|
? |
EK8961
|
SEAL, UPPER MODULE |
2 |
|
|
|
|
? |
58F-06-42230
|
PANEL, STATUS |
1 |
|
|
|
|
? |
SM2466
|
SCREW - #10 - 24NC X 1" |
4 |
|
|
|
|
? |
EL5675
|
DASH PANEL, MOLDED |
1 |
|
|
|
|
? |
SM5145
|
TUBE (2) |
2 |
|
|
|
|
? |
WA4513
|
SCREW - #10 - 24NC X 1/2" (2) |
4 |
|
|
|
|
? |
CC6103
|
CLAMP, WORM DRIVE |
4 |
|
|
|
|
? |
SM2783
|
HOSE, AIR |
2 |
|
|
|
|
? |
EK7946
|
ADAPTER, HOSE |
2 |
|
|
|
|
? |
SM4435
|
PLATE, BENT-FILLER |
1 |
|
|
|
|
? |
PC1938
|
HARNESS, WIRING - MAIN GAUGE PANEL |
1 |
|
|
|
|
? |
PC1939
|
HARNESS, WIRING - STATUS LIGHT PANEL |
1 |
|
|
|
|
? |
|
NOTE: (1) NOT SERVICED AS AN ASSEMBLY. ORDER |
-1 |
|
|
|
|
? |
|
INDIVIDUAL COMPONENT PARTS. |
-1 |
|
|
|
|
? |
|
(2) NOT INCLUDED IN THE INSTRUMENT PANEL ASSM. |
-1 |
|
|
