Komatsu parts book diagram for D475A-8E0 S/N 51001-UP: CONTROL UNIT, AIR CONDITIONER UNIT (2/3)(#50001-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	20Y-979-8412	Air Conditioner	1	SN: 50001-UP
	?	ND117300-7241	Motor Assembly	1	SN: 50001-UP
	?	ND116243-1560	Case	1	SN: 50001-UP
	?	ND116243-1550	Case	1	SN: 50001-UP
	?	ND017321-4600	Case	1	SN: 50001-UP
	?	ND116360-2760	Motor Assembly	1	SN: 50001-UP
	?	ND077800-1140	Transistor	1	SN: 50001-UP
	?	ND063600-4580	Servo Motor Assembly	1	SN: 50001-UP
	?	ND116662-8530	Shaft	1	SN: 50001-UP
	?	ND116782-6720	Lever	1	SN: 50001-UP
	?	ND116740-8490	Door Assembly	1	SN: 50001-UP
	?	ND949008-0330	Screw, Tapping	3	SN: 50001-UP
	?	ND077500-5650	Thermistor Assembly	1	SN: 50001-UP
	?	ND017661-3560	Bracket	1	SN: 50001-UP
	?	ND949001-1730	Screw, Tapping	11	SN: 50001-UP
	?	ND146636-7530	Packing	1	SN: 50001-UP
	?	ND146636-7540	Packing	1	SN: 50001-UP
	?	ND146636-7550	Packing	1	SN: 50001-UP
	?	ND146651-1840	Pipe	1	SN: 50001-UP

Komatsu D475A-8E0 S/N 51001-UP parts catalog PDF

CONTROL UNIT, AIR CONDITIONER UNIT (2/3)(#50001-) (K0220-032014) in D475A-8E0 S/N 51001-UP. Diagram image and parts list.
