AFE77-CN 830E-5 S/N A50294 - A50295 SMS

Komatsu parts book diagram for AFE77-CN 830E-5 S/N A50294 - A50295 SMS: STEERING PUMP SEAL INSTALLATION

? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	58E-98-00050	O-RING	2
	?	XA0196	SEAL	1
	?	58E-98-20360	SEAL	1
	?	58E-98-00040	RING, BACKUP	2
	?	58E-98-00020	O-RING	1
	?	VE9581	RING, PISTON	1
	?	58E-98-00030	RING, BACKUP	1
	?	VE9598	O-RING	1
	?	VE9532	SEAL, SHAFT	1
	?	VE9539	O-RING	1
	?	VE9549	GASKET	1
	?	VE9551	O-RING	1
	?			-1
	?		(SEE FOLLOWING PAGES FOR BALANCE OF STEERING	-1
	?		PUMP ASSEMBLY COMPONENT PARTS.)	-1

Komatsu AFE77-CN 830E-5 S/N A50294 - A50295 SMS parts catalog PDF

STEERING PUMP SEAL INSTALLATION (68144) in AFE77-CN 830E-5 S/N A50294 - A50295 SMS. Diagram image and parts list.
