ALTERNATOR ASSEMBLY 1/6 | AFE78-EM 930E-5 S/N A40502 - A40505 KSA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE78-EM 930E-5 S/N A40502 - A40505 KSA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	58F-06-11303	ALTERNATOR/BLOWER ASSEMBLY	1
?	58F-43-03101	ROTOR ASSEMBLY (SEE FIG 69511)	1	69511
?	58F-43-03160	STATOR ASSEMBLY (SEE FIG 45662)	1	45662
?	VJ2743	PIN, SPRING DOWEL	1
?	58F-43-03211	HEAD, FRAME	1
?	58F-06-05860	CABLE, SPEED SENSOR	1
?	VE6085	CAPSCREW - 1/4" - 20NC X 1"	4
?	VE7202	WASHER - 1/4"	4
?	PB0101	SENSOR, SPEED	1
?	VE3620	PIN, DOWEL	1
?	GE0315	HUB	1
?	VE3042	IMPELLER	1
?	VE4997	BAFFLE	1
?	58F-43-03260	HOUSING, INLET	1
?	GE0333	BAFFLE	1
?	58F-43-03270	CONNECTOR ASSEMBLY	1
?	XA4446	ADAPTER	1
?	VE4489	CAPSCREW - 1/2" - 13NC X 1 1/4"	8
?	VE4999	CAPSCREW - 1/2" - 13NC X 2"	12
?	VE5185	FLAT WASHER - 1/2"	20
?	VE5000	CAPSCREW - 3/8" - 16NC X 2 1/4"	8
?	VE4500	CAPSCREW - 3/8" - 16NC X 1 3/4"	12
?	VE3027	FLAT WASHER - 3/8"	20
?	GE0141	CAPSCREW - 5/8" - 11NC X 2 1/4"	6
?	VE4631	FLAT WASHER	6
?	VE4994	CAPSCREW - 5/8" - 18NC X 2 1/4"	15
?	VE5184	FLAT WASHER	21
?	58F-43-03290	ROTOR, LOCK	2
?	XA4217	CAPSCREW - 5/8" - 11NC X 2"	2
?	58F-06-01560	CAPSCREW - 5/8" - 11NC X 5 1/2"	4
?	GE1362	FLAT WASHER - 5/8"	6
?	58F-43-03300	ROTOR, LOCK PLATE	2
?	58D-43-00530	SETSCREW	1
