AFE84-P 730E-10 S/N A50051 - A50054 KAL

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	58E-06-50200	ISOLATION BOX	1
?	58E-06-50620	PLATE	1
?	MM0595	CAPSCREW - M8 X 1.25 X 30	6
?	MM0470	LOCKWASHER - M8	6
?	MM0460	FLAT WASHER - M8	6
?	MM0344	MACHINE SCREW - M4 X 0.7 X 20	4
?	MM0378	LOCKWASHER, EXTERNAL TOOTH - M4	8
?	MM0372	NUT - M4 X 0.7	4
?	MM0607	CAPSCREW - M10 X 1.50 X 35	8
?	MM0471	LOCKWASHER - M10	8
?	MM0178	NUT - M10 X 1.50	8
?	58E-06-50270	RELAY BOX ASSEMBLY	1
?	58E-06-01311	HARNESS, WIRING - ISOLATION BOX INTERNAL	1
?	PC2528	SWITCH, LOCKOUT	1
?	TC1231	LOCKWASHER - 3/8"	2
?	MM0461	FLAT WASHER - M10	18
?	DC3101	LOCKWASHER - #10	5
?	HD8390	FLAT WASHER, COPPER - # 10	2
?	VC5344	FLAT WASHER - #10	3
?	VN7121	MACHINE SCREW - # 10 - 24NC X 1/2"	3
?	58E-06-50340	BUS BAR	1
?	58E-06-50350	BUS BAR	1
?	58E-06-50360	BUS BAR	1
?	58E-06-50370	BUS BAR	1
?	DF3500	LOCKNUT - 1/2" - 13NC	4
?	MM0578	CAPSCREW - M6 X 1.00 X 10	4
?	SD4235	LOCKWASHER, EXTERNAL TOOTH - 1/4"	4
?	58E-06-50610	PLATE	1
?	SM6022	VALVE, VACUUM	1
?	HC0908	CLAMP, WORM DRIVE	1
?	C1639	CAPSCREW - 5/16" - 18NC X 2"	1
?	VN9951	LOCKNUT - 5/16" - 18NC	1
?	PB6842	HOOK, RUBBER	1
