ALTERNATOR ASSEMBLY 2/4 | AFE84-R 730E-10 S/N A50056 - A50058 KSA

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

AFE84-R 730E-10 S/N A50056 - A50058 KSA

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity	Reference
?	58D-06-20012	ALTERNATOR / BLOWER ASSEMBLY	1
?	VE8444	BRUSH	6
?	58D-98-03460	CABLE, SPEED SENSOR	1
?	GE1155	SENSOR, SPEED	1
?	XA4446	ADAPTER	1
?	58D-98-01950	STATOR ASSEMBLY, TERTIARY COILS (SEE FIG 48478)	1	48478
?	58D-43-00610	FRAME, HEAD	1
?	VJ1073	CAPSCREW - 5/8" -18NF X 2 1/4"	15
?	58D-98-00360	CAPSCREW - 1/2" - 13NC X 1 1/2"	8
?	VE4500	CAPSCREW - 3/8" - 16NC X 1 3/4"	44
?	VE3027	FLAT WASHER - 3/8"	2
?	VE5185	FLAT WASHER - 1/2"	8
?	VE5184	FLAT WASHER	15
?	VE4747	NUT	23
?	VJ2743	PIN, SPRING DOWEL	1
?	GE1172	PLUG, PIPE	1
?	58D-98-01380	CAPSCREW - 5/8" - 11NC X 2"	2
?	VE2316	PLUG, PIPE - 1/8"	2
?	58F-43-03290	ROTOR, LOCK	2
?	58F-06-01560	CAPSCREW - 5/8" - 11NC X 5 1/2"	4
?	GE0042	FLAT WASHER - 5/8"	6
?	58D-43-00550	BAFFLE	1
?	VE4640	CAPSCREW - 3/8" - 16NC X 1 1/2"	1
?	58D-98-00840	FLAT WASHER - 3/8"	4
?	58D-98-03300	ROTOR ASSEMBLY (SEE FIG 46241)	1	46241
?	58D-98-03420	TERMINAL ASSEMBLY	3
?	58D-98-03430	CLAMP ASSEMBLY	1
?	58D-98-01930	PLATE, CLAMP	1
?	VE4696	LOCKWASHER - 5/16"	2
?	BF0543	CAPSCREW - 5/16" - 18NC X 2 1/2"	2
?	VE4648	FLAT WASHER - 5/16"	6
?	VE4697	CAPSCREW - 5/16" - 16NC X 2"	3
?	VE4626	NUT - 5/16" - 18NC	3
?	58D-98-01940	PUTTY, AIR DRY	-2
?	VE4334	TAPE	-2
?	VE4335	TAPE, FIBERGLASS	-2
?	VE3915	VARNISH - 1 GALLON	-2
