HD325-7R S/N 12001-UP

Komatsu parts book diagram for HD325-7R S/N 12001-UP: PLATFORM MOUNTING, (#11034-)

? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	01010-82050	Bolt	2	SN: 11034-UP
	?	01010-82050	Bolt	2	SN: 11034-UP
	?	01643-32060	Washer	4	SN: 11034-UP
	?	09415-05016	Cap	4	SN: 11034-UP
	?	566-54-81391	Guard	1	SN: 11034-UP
	?	566-54-8A915	Platform(Platform Group,Platform,With KOMTRAX)	-1	SN: UP	L3150-011002
	?	566-54-8A915	Platform(Platform Group,Platform)	-1	SN: UP	L3150-012002

Komatsu HD325-7R S/N 12001-UP parts catalog PDF

PLATFORM MOUNTING, (#11034-) (L3120-001001) in HD325-7R S/N 12001-UP. Diagram image and parts list.
