|$0 |
708-2K-00113
|
Pump Assembly |
1 |
SN: 65001-@
|
|
|
|
|$1 |
708-1W-00901
|
Pump Assembly |
1 |
SN: 65001-65050
|
|
|
|
|$2 |
708-1W-00912
|
Pump Assembly |
1 |
SN: 65027-65050
|
|
|
|
|$3 |
708-1W-00911
|
Pump Assembly |
1 |
SN: 65001-65026 | SCC: A2
|
|
|
|
|$4 |
708-1W-01917
|
Pump Subassembly |
1 |
SN: 65027-65050 | SCC: C2
|
|
|
|
|$5 |
708-1W-01916
|
Pump Subassembly |
1 |
SN: 65001-65026 | SCC: C2
|
|
|
|
1 |
708-1W-43310
|
Cylinder Block |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
2 |
708-1W-43220
|
Plate, Valve |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
3 |
720-68-19610
|
Pin |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
4 |
708-1W-43130
|
Seat |
2 |
SN: 65001-65050 | SCC: C2
|
|
|
|
5 |
708-1W-43140
|
Spring |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
6 |
04065-04818
|
Ring, Snap |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
7 |
708-1W-43320
|
Guide, Retainer |
1 |
SN: 65027-65050 | SCC: C2
|
|
|
|
|$13 |
708-1W-43350
|
Guide, Retainer |
1 |
SN: 65001-65026 | SCC: C2
|
|
|
|
8 |
708-3T-13360
|
Pin |
3 |
SN: 65001-65050 | SCC: C2
|
|
|
|
9 |
708-1W-43341
|
Retainer, Shoe |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
10 |
708-1U-13310
|
Piston Subassembly |
9 |
SN: 65001-65050 | SCC: C2
|
|
|
|
11 |
708-1W-44130
|
Piston |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
12 |
708-3T-14120
|
Spring |
1 |
SN: 65001-65050 | SCC: C2
|
|
|
|
13 |
708-1U-14240
|
Screw |
2 |
SN: 65001-65050 | SCC: C2
|
|
|
|
14 |
07000-12011
|
O-ring |
2 |
SN: 65001-65050 | SCC: C2
|
|
|
|
15 |
01643-31232
|
Washer |
2 |
SN: 65001-65050 | SCC: C2
|
|
|
|
16 |
01582-11210
|
Nut |
2 |
SN: 65001-65050 | SCC: C2
|
|
|
|
|$23 |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
|$24 |
|
[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
