D39PXI-24 S/N 110001-UP

Komatsu parts book diagram for D39PXI-24 S/N 110001-UP: HYDRAULIC PUMP, HST PUMP (9/11)(#100001-)

? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	720-2M-00131	Pump Assembly	1	SN: 100421-UP
	?	720-2M-00130	Pump Assembly	1	SN: 100001-100420 \| SCC: A2
	?	720-2M-01131	Pump Subassembly	1	SN: 100421-UP \| SCC: C2
	?	720-2M-01130	Pump Subassembly	1	SN: 100001-100420 \| SCC: C2
	?	720-2M-03290	Cover Assembly	1	SN: 100001-UP \| SCC: C2
	?	720-2M-14530	Cover	1	SN: 100001-UP \| SCC: C2
	?	720-2M-14170	Screw	1	SN: 100001-UP \| SCC: C2
	?	07000-B1010	O-ring	1	SN: 100001-UP \| SCC: C2
	?	01582-11210	Nut	1	SN: 100001-UP \| SCC: C2
	?	07000-B2075	O-ring	2	SN: 100001-UP \| SCC: C2
	?	01582-11210	Nut	1	SN: 100001-UP \| SCC: C2
	?	01252-61025	Bolt, Hexagon Socket Head	8	SN: 100001-UP \| SCC: C2
	?	708-2M-12130	Coupling	1	SN: 100001-UP \| SCC: C2
	?	708-2M-12140	Ring	1	SN: 100001-UP \| SCC: C2
	?		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP
	?		[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP
