PC2000-11R S/N 31001-UP

Komatsu parts book diagram for PC2000-11R S/N 31001-UP: NO.1 PUMP, PISTON PUMP (4/9)(#30001-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	708-2K-00140	Pump Assembly	1	SN: 30001-UP
	?	708-2K-01140	Pump Subassembly	1	SN: 30001-UP \| SCC: C2
	?	708-2K-04470	Case Assembly	1	SN: 30001-UP \| SCC: C2
	?		Case	1	SN: 30001-UP \| SCC: C1
	?		Plug, Stocking	3	SN: 30001-UP \| SCC: C1
	?	708-2K-11170	O-ring	3	SN: 30001-UP \| SCC: C2
	?	708-2K-11190	O-ring	1	SN: 30001-UP \| SCC: C2
	?	708-2K-11950	Plate	1	SN: 30001-UP
	?	07000-A2140	O-ring	1	SN: 30001-UP
	?	01010-81025	Bolt	4	SN: 30001-UP
	?	708-2K-11920	Plug	1	SN: 30001-UP
	?	07002-64234	O-ring	1	SN: 30001-UP
	?	20B-27-11210	Bleeder	1	SN: 30001-UP
	?	07044-13620	Plug	1	SN: 30001-UP
	?	07002-63634	O-ring	1	SN: 30001-UP
	?	04530-12030	Bolt, Eye	1	SN: 30001-UP
	?	708-2K-11290	Orifice	1	SN: 30001-UP \| SCC: C2
	?		[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP
	?		[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu PC2000-11R S/N 31001-UP parts catalog PDF

NO.1 PUMP, PISTON PUMP (4/9)(#30001-) (H0210-001004) in PC2000-11R S/N 31001-UP. Diagram image and parts list.
