PC2000-11R S/N 31001-UP

Komatsu parts book diagram for PC2000-11R S/N 31001-UP: COOLING SYSTEM, UPPER PIPING(#30001-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	21T-03-43710	Tube	1	SN: 30001-UP
	?	21T-03-43720	Tube	1	SN: 30001-UP
	?	01010-81225	Bolt	4	SN: 30001-UP
	?	175-54-34170	Washer	4	SN: 30001-UP
	?	21T-03-41391	Hose	2	SN: 30001-UP
	?	21T-03-43381	Hose	2	SN: 30001-UP
	?	07289-00095	Clamp	12	SN: 30001-UP
	?	07289-00080	Clamp	4	SN: 30001-UP

Komatsu PC2000-11R S/N 31001-UP parts catalog PDF

COOLING SYSTEM, UPPER PIPING(#30001-) (C0100-003018) in PC2000-11R S/N 31001-UP. Diagram image and parts list.
