LUBE PUMP, HYDR. | PC8000-1E S/N 12024 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

PC8000-1E S/N 12024

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

#	Part Number	Partname	Quantity
?	698 245 73	Hydr. grease pump, H 55, H 65 (25 l) H 55, H 65	1
?	698 246 73	Hydr. grease pump, H 95, H 135 (60 l) H 95, H 135	1
?	698 247 73	Hydr. grease pump, H 185 - H 485 (200 l) H 185 - H 485	1
?	693 938	Suction tube to fig-no: 01	1
?	764 523 73	Suction tube to fig-no: 02	1
?	693 825	Suction tube to fig-no: 03	1
?	693 939	Piston rod to fig-no: 01	1
?	764 524 73	Piston rod to fig-no: 02	1
?	693 827	Piston rod to fig-no: 03	1
?	693 814	Pin	1
?	697 756 73	Piston	1
?	693 816	Bushing	1
?	693 817	Disc	1
?	693 818	Seal ring	1
?	693 819	Seal	1
?	693 820	Sliding ring	1
?	693 821	O-ring	1
?	693 822	V-seal	1
?	693 823	Elastic washer	1
?	697 755 73	Seal	1
?	693 829	Piston guide	1
?	693 830	Seal	1
?	693 831	Bushing	1
?	693 832	Bolt	1
?	693 833	Pin	1
?	698 248 73	Ball retainer	2
?	698 249 73	Ball	2
?	693 835	Seal	2
?	697 749 73	Cylinder assy.	1
?	696 081 73	Seal ring	1
?	698 250 73	Ball seat	1
?	693 837	Valve stop	1
?	693 838	Seal ring	1
?	693 839	Distance plate	1
?	697 275 73	Valve	1
?	697 276 73	Valve seat	1
?	693 836	Rod	1
?	697 277 73	Suction piston	1
?	697 750 73	Extension piece	1
?	698 251 73	Suction tube	1
?	698 252 73	Housing	1
?	698 278 73	Cylinder	1
?	698 253 73	Mounting plate	1
?	698 254 73	Rod	4
?	698 255 73	Nut	1
?	764 525 73	Repair kit - pump	1
?	698 257 73	Bolt	4
?	698 258 73	Lock washer	12
?	698 259 73	Lock washer	2
?	698 260 73	Bolt	8
?	695 729 73	Bolt	2
?	698 261 73	Bolt	2
?	698 262 73	Housing	1
?	698 263 73	Union	1
?	698 264 73	Lock washer	2
?	698 265 73	Valve combination	1
?	698 266 73	Hose	1
?	698 267 73	Seal	2
?	698 268 73	Hose	1
?	698 269 73	Adapter	2
?	698 270 73	3-Way-valve	1
?	698 271 73	4-Way-valve	1
?	698 272 73	Field coil	2
?	698 273 73	Pressure reducing valve	1
?	698 274 73	Cable union	2
?	698 275 73	Pressure gauge	1
?	698 276 73	Flow control valve	1
?	698 277 73	Valve housing	1
?	697 141 73	Union	1
?	698 418 73	Plug (for pressure lubrication)	1
?	764 161 73	Repair kits to suction tube 01-03 consist. of fig-nos: 27,30,31,33-38	1
?	006 695 98	O-ring to fig-nos. 61,62	2
