HYDR. PUMP | PC8000-1E S/N 12024 | Komatsu parts book catalogue

Search in All Books

Find books across the catalog from one place.

This page is prepared as the search workspace. The search behavior itself can be connected in the next step.

Search whole Komatsu part number in all books. Example: 6212611203.

#	Part Number	Partname	Quantity
01	604 988 40	Hydr. pump	1
02		Housing	1
03	319 187 99	Screw	7
04	319 190 99	Screw	1
05	754 667	Connection plate	1
06	344 888 99	Pin	2
07	763 865 73	Gasket	1
08	502 596 98	Thread pin	1
09	504 762 98	Thread pin	1
10	964 767	Nut	2
11	754 669	Regulation journal	1
12	173 448 40	Plug	3
13	763 866 73	Transmission, assy. fig-nos: 14,15,23,31-37	1
14	763 867 73	Control lense	1
15	763 868 73	Transmission, hydr. part, assy. fig-nos: 16-22	1
16	763 869 73	Cylinder	1
17	754 674	Spring plate	1
18	754 675	Cup spring	4
19	754 676	Trunnion	1
20	763 872 73	Piston with piston ring	7
21	762 748 73	Screw, burnished	14
22	998 793	Withdrawal plate	1
23	763 870 73	Drive shaft with bearing set with fig-nos: 24-30	1
24		Roller bearing These parts are not sold separately	1
25		Shim ring These parts are not sold separately	2
26		Shim ring These parts are not sold separately	1
27		Shim ring These parts are not sold separately	1
28		Roller bearing These parts are not sold separately	1
29		Race These parts are not sold separately	1
30		Groove nut These parts are not sold separately	1
31	342 682 99	Circlip	1
32	754 679	Disk	1
33	006 746 98	O-ring	1
34	504 216 98	Shaft seal	2
35	754 680	Adjusting disk	1
36	754 681	Cover	1
37	754 682	Snap ring	1
\|$$38	763 871 73	Repair kit, assy. fig-nos: 07,10,12,31,33-36	-2
\|$$39	973 125	Fluid sealing to fig-no: 21 50 ml	-2
\|$$40	989 946	Fluid sealing (pipe thread) 50 ml (Rohrgewinde)	-2
