PC8000-1E S/N 12024

Komatsu parts book diagram for PC8000-1E S/N 12024: SLEW RING

01 02 03 04 05 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19

	#	Part Number	Partname	Quantity	Options	Reference
	01	642 500 40	Slew ring assy.	1
	02	642 509 40	Bearing rac assy. fig-nos: 03-06 No field repair item	1
	03	642 501 40	Bearing race	1
	04	642 507 40	Intermediate ring	1
	05	504 728 98	Tooth lock washer	22
	06	319 339 99	Bolt	22
	07	642 503 40	Bearing race No field repair item	1
	08	642 505 40	Retaining ring No field repair item	1
	09	505 447 40	Roller set No field repair item	1
	10	505 373 40	Roller set No field repair item	1
	11	517 653 40	Roller set No field repair item	1
	12	505 457 40	Cage No field repair item	128
	13	487 146 40	Cage No field repair item	187
	14	368 550 40	Extension No field repair item	258
	15	320 156 99	Bolt	22
	16	224 640 40	Lip type seal NG 40x13200 mm Bulk ware, state length required	1
	17	224 639 40	Lip type seal NG 25x13200 mm Bulk ware, state length required	1
	18	504 916 98	Grease (1,0 kg.)	50
	19	989 965	Adhesive	1

Komatsu PC8000-1E S/N 12024 parts catalog PDF

SLEW RING (112-1115d) in PC8000-1E S/N 12024. Diagram image and parts list.
