D61PX-24 S/N 48001-UP

Komatsu parts book diagram for D61PX-24 S/N 48001-UP: CAB, DC CONVERTER(#46272-)

? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	2A5-06-11881	Converter	1	SN: 46272-UP
	?	01252-B0520	Bolt	2	SN: 46272-UP
	?	01640-50508	Washer	2	SN: 46272-UP
	?	14X-06-52492	Socket Assembly	2	SN: 46272-UP
	?	12Y-54-28991	Bracket	1	SN: 46272-UP
	?	2A5-00-11370	Plate, 12volt	1	SN: 46272-UP
	?	01245-00825	Screw	2	SN: 46272-UP
	?	01643-70823	Washer	2	SN: 46272-UP

Komatsu D61PX-24 S/N 48001-UP parts catalog PDF

CAB, DC CONVERTER(#46272-) (K0210-025023) in D61PX-24 S/N 48001-UP. Diagram image and parts list.
