134-30-01032
|
Track Roller Assembly, Double Flange |
1 |
SN: 41373-UP
|
|
|
|
? |
134-30-01031
|
Track Roller Assembly, Double Flange |
4 |
SN: 40653-41372 | SCC: A1
|
|
|
|
? |
134-30-01030
|
Track Roller Assembly, Double Flange |
4 |
SN: 40001-40652 | SCC: A2
|
|
|
|
? |
131-30-61420
|
Roller, Track, Double Flange |
1 |
SN: 40001-UP
|
|
|
|
? |
131-30-61331
|
Bushing |
2 |
SN: 40653-UP
|
|
|
|
? |
131-30-61330
|
Bushing |
2 |
SN: 40001-40652 | SCC: A2
|
|
|
|
? |
131-30-36131
|
Shaft |
1 |
SN: 40001-UP
|
|
|
|
? |
07052-31217
|
Plug |
1 |
SN: 40001-UP
|
|
|
|
? |
07000-02055
|
O-ring |
2 |
SN: 40001-UP
|
|
|
|
? |
198-30-00770
|
Floating Seal Assembly |
2 |
SN: 41373-UP
|
|
|
|
? |
205-30-00220
|
Floating Seal Assembly |
2 |
SN: 40001-41372
|
|
|
|
? |
|
Seal |
2 |
SN: 41373-UP | SCC: C1
|
|
|
|
? |
|
Seal |
2 |
SN: 40001-41372 | SCC: C1
|
|
|
|
? |
|
O-ring |
2 |
SN: 40001-UP | SCC: C1
|
|
|
|
? |
131-30-61351
|
Collar |
2 |
SN: 40001-UP
|
|
|
|
? |
131-30-36150
|
Ring, Snap |
2 |
SN: 40001-UP
|
|
|
|
? |
131-30-36160
|
Key |
2 |
SN: 40001-UP
|
|
|
|
? |
01010-81670
|
Bolt |
64 |
SN: 40001-UP
|
|
|
|
? |
01643-31645
|
Washer |
64 |
SN: 40001-UP
|
|
|
|
? |
|
[A1]-This part and the part specified in the line immediately above are interchangeable. |
-1 |
SN: UP
|
|
|
|
? |
|
[A2]-The part specified in the line above can be used instead of this part. |
-1 |
SN: UP
|
|
|
|
? |
|
[C1]-This part cannot be supplied as an individual part. It is supplied as an assembly. |
-1 |
SN: UP
|
|
