D61PX-24 S/N 48001-UP

Komatsu parts book diagram for D61PX-24 S/N 48001-UP: DOZER BLADE, (#46093-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	13Y-72-21202	Blade	1	SN: 45917-UP
	?	13Y-72-11160	Bracket, Welded	2	SN: 40001-UP
	?	13Y-72-11170	Bracket, Welded	1	SN: 40001-UP
	?	134-72-61450	End Bit	1	SN: 40001-UP
	?	134-72-61460	End Bit	1	SN: 40001-UP
	?	13G-72-61410	Cutting Edge	1	SN: 40001-UP
	?	13G-72-61420	Cutting Edge	2	SN: 40001-UP
	?	02090-11265	Bolt	32	SN: 40001-UP
	?	02290-11219	Nut	32	SN: 40001-UP
	?	13Y-72-11183	Cover	1	SN: 40001-UP
	?	01010-81225	Bolt	6	SN: 40001-UP
	?	01643-31232	Washer	6	SN: 40001-UP
	?	01010-81625	Bolt	4	SN: 45710-UP
	?	01643-31645	Washer	4	SN: 45710-UP
	?	09601-60000	Plate, Name (Limited Supply)	1	SN: 46093-UP \| SCC: C2
	?	04418-13060	Screw	4	SN: 46093-UP
	?		[C2]-This part is supplied for authorized Komatsu distributors only. It cannot be supplied as an individual part. It is supplied as an assembly.	-1	SN: UP

Komatsu D61PX-24 S/N 48001-UP parts catalog PDF

DOZER BLADE, (#46093-) (T2120-001001B) in D61PX-24 S/N 48001-UP. Diagram image and parts list.
