PC490LC-11 S/N 87001-UP

Komatsu parts book diagram for PC490LC-11 S/N 87001-UP: REARVIEW MIRROR L.H., (#85001-)

? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	2A5-54-13421	Mirror	1	SN: 85415-UP
	?	2A5-54-13420	Mirror	1	SN: 85001-85414 \| SCC: A2
	?	2A5-54-16120	Support	1	SN: 85001-UP
	?	20Y-54-35430	Clamp	1	SN: 85001-UP
	?	01252-A1030	Bolt, Hexagon Socket Head	2	SN: 85001-UP
	?		[A2]-The part specified in the line above can be used instead of this part.	-1	SN: UP

Komatsu PC490LC-11 S/N 87001-UP parts catalog PDF

REARVIEW MIRROR L.H., (#85001-) (M1410-001001) in PC490LC-11 S/N 87001-UP. Diagram image and parts list.
