PC490LC-11 S/N 87001-UP

Komatsu parts book diagram for PC490LC-11 S/N 87001-UP: ELECTRIC WIRING HARNESS, ELECTRIC PRIMING PUMP SWITCH(#87001-)

? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	208-06-41371	Bracket	1	SN: 87001-UP
	?	600-815-9780	Switch, Priming Pump	1	SN: 87001-UP
	?	01010-80820	Bolt	4	SN: 87001-UP
	?	01643-30823	Washer	4	SN: 87001-UP
	?	08504-10000	Cap	1	SN: 87001-UP

Komatsu PC490LC-11 S/N 87001-UP parts catalog PDF

ELECTRIC WIRING HARNESS, ELECTRIC PRIMING PUMP SWITCH(#87001-) (E0200-023012) in PC490LC-11 S/N 87001-UP. Diagram image and parts list.
