PC350LC-8M0 S/N 85001-UP

Komatsu parts book diagram for PC350LC-8M0 S/N 85001-UP: FLOOR MOUNTING, (#80107-)

? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ? ?

	#	Part Number	Partname	Quantity	Options	Reference
	?	208-53-23210	Cushion	2	SN: 80107-UP
	?	206-53-13121	Cushion	2	SN: 80107-UP
	?	01580-12016	Nut	4	SN: 80107-UP
	?	01643-32060	Washer	4	SN: 80107-UP
	?	20Y-53-13130	Spacer	4	SN: 80107-UP
	?	01010-81235	Bolt	16	SN: 80107-UP
	?	01643-31232	Washer	16	SN: 80107-UP
	?	2A5-53-11941	Plate	1	SN: 80107-UP
	?	20Y-53-13142	Plate	1	SN: 80107-UP
	?	01011-83080	Bolt	1	SN: 80107-UP
	?	01643-33080	Washer	1	SN: 80107-UP
	?	20Y-53-13152	Lock	1	SN: 82562-UP
	?	20Y-53-13151	Lock,(20Y-53-13152,01010-81235,175-54-34170,2A5-53-14370)	1	SN: 80107-82561 \| SCC: A4
	?	01010-81235	Bolt	1	SN: 80107-UP
	?	175-54-34170	Washer	1	SN: 82562-UP
	?	01643-31232	Washer	1	SN: 80107-82561
	?	2A5-53-14370	Collar	1	SN: 82562-UP
	?	198-43-15310	Collar	1	SN: 80107-82561
	?		[A4]-The part specified in the description column can be used instead of this part if it is used as a set.	-1	SN: UP

Komatsu PC350LC-8M0 S/N 85001-UP parts catalog PDF

FLOOR MOUNTING, (#80107-) (K1120-004001) in PC350LC-8M0 S/N 85001-UP. Diagram image and parts list.
